7 Technical Specifications

LAN port
PHONE1 port
PHONE2 port
PHONE3 port
Port status LED's
Switching
PoE Bridge
USB Version
USB Profile
USB Current
USB Connector
Button
LED's (4x)
Size ( L x B x H )
Housing material
Weight
Temperature Range : 0 – 40 °C
Humidity Range
EMC
Safety
RoHS
V-Tap VoIP Manual EN v2.7 Oct 2018
: RJ45, Ethernet 10BASE-T, 100BASE-T, full duplex
: RJ45, Ethernet 10BASE-T, 100BASE-T, full duplex
: RJ45, Ethernet 10BASE-T, 100BASE-T, full duplex, PoE to PHONE3
: RJ45, Ethernet 10BASE-T, 100BASE-T, full duplex, PoE to PHONE2
: 10/100Mb with Rx/Tx activity blinking on all 4 Ethernet ports.
: L2 switching on all Ethernet ports.
: PoE is passively bridged from PHONE2 to PHONE3,
So, if the cable carries PoE, it is bridged to the other port.
Note that the V-Tap VoIP does not generate PoE by itself.
: V2.0 High Speed (480Mbps)
: Generic HID (VID: 0DE1
: 5V @400mA (Max. 2W)
: Full size 'B'- type
: Function as described here:
: Function as described here:
: 90 x 125 x 28 mm
: Blue bottom with Silver top, 4 pcs soft rubber footpads.
: 150 Gram
: 10 – 90 %, non condensing
: EN 55022:2010 / AC:2011 Class B , EN 55024:2010
: EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011
: EN 50581:2012 (RoHS2) , RoHS Directive 2011/65/EU
/ PID: 3101
(16) (16)
Button functions
LED's
© 2017-2018 Vidicode
IEEE 802.3af.
