3.3.8

The button can be used to manually start and stop recording calls. Other

special functions of the button are described in chapter

Button Mode: 1=Start 2=Stop

Manual recording with the button is enabled when this setting is other

than zero. Manually starting and stopping is used when one phone is

connected and the user can press the button on the V-Tap. This only

works well in combination with an SD card!

The following values can be entered:

1 = Start mode. Each call starts with the Red LED OFF (not recording).

The user must press the button before or during the call to save

the recorded data. Non-saved calls are deleted from the SD card.

2 = Stop mode. Each call starts with the Red LED ON (recording).

The user must press the button before or during the call to cancel

saving of the data. Non-saved calls are deleted from the SD card.

3 = Start-Stop mode. The state of the Red LED does not change in

between calls. After power on or saving settings, the Red LED

is OFF, so the V-Tap is not recording calls.

mode + 4 = When 4 is added to the mode, the V-Tap is in 'pre-recording'

mode, meaning that all audio of all calls is always stored, even after

stopping with the button. Normally, the audio storage is stopped or

started when the button is pressed. The decision to keep or delete the

recording is made at the end of each call, depending on the state of the

Red LED at that time. One advantage is, that the user can press the

button in the middle of a call to 'start' it and then the complete call

from the beginning is saved.

mode + 8 = The non-saved calls are kept on the SD card, but are NOT

sent to the Tunnel server. Keeping these files can be used for safety

reasons, giving the possibility to retrieve them later. These files have a

different file name and are only deleted from the card when

overwritten or by the "SD Delete File after Sending" function.

Watch the Red LED: ON=Started , OFF=Stopped
