6 Connection schemes

In the following paragraphs, the connection schemes for some situations
of connecting things are drawn. The settings to change these different
ways of operating are described in
NOTE: Only ports PHONE2 and PHONE3 are suitable to connect an
external Power over Ethernet (PoE) loop.
The V-Tap itself does not generate PoE.

6.1 Tunnel function

This is the default startup situation of the V-Tap VoIP.
All ports can be used for web access, VoIP data and Tunnel connection.
