- Page 1 User Manual AZ430 WAN Satellite Modem version 1.0 SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS...
- Page 2 User Manual for AZ430 WAN Satellite Modem © 2009 Newtec cy. The material contained in this document is confidential and intended for use only by parties authorised by Newtec. All Rights Reserved. No part of this document may be photocopied, reproduced,...
- Page 3 User Manual for AZ430 WAN Satellite Modem Compliancy Statements COMPLIANCY STATEMENTS TO WHOM IT MAY CONCERN EC DECLARATION OF CONFORMITY NEWTEC CY nv. Declare that the following product: Product number: with type identifiers : NTC/2210 (IF) and NTC/2215 (L-Band) to which this declaration relates is in conformity with the essential requirements of European Union Directive 1999/5/EC Radio and Telecommunication Terminal Equipment Directive Essential Requirement 3.1(a), 3.1 (b), 3.2.
- Page 4 As in time more and more Newtec equipment will be totally leadless, we will inform you on the status of the equipment you intend to use at that time.
- Page 5 Only qualified personnel who are aware of hazards involved may adjust, maintain and repair the equipment. The AZ430 Telco Satellite Modem has no operator serviceable parts inside. Refer servicing to qualified personnel. To prevent electrical shock, do not remove covers.
- Page 6 User Manual for AZ430 WAN Satellite Modem Safety Regulations Additional safety requirements for Finland, Norway and Sweden Telecommunication connections and cable distribution system. Special conditions apply to the use of this equipment in Finland, Sweden and Norway due to different earthing arrangements in these countries.
- Page 7 The warranty only applies to manufacturing defects and only when the equipment is handled, installed, maintained and adjusted in line with the instructions provided by Newtec and in line with good practice. The warranty does not apply to items normally consumed in operation or which have a normal life time inherently shorter than the warranty stated above, such as, without limitation, fuses or lamps.
- Page 8 User Manual for AZ430 WAN Satellite Modem About this Manual ABOUT THIS MANUAL This document provides a quick overview on how to easily set up the modem for the most common use cases. This document is intended to help you: •...
- Page 9 User Manual details the linear and non-linear pre-distortion capabilities. • The RMCP manual explains how Newtec devices can be remotely monitored and controlled via the serial port or via Ethernet. A copy of a separate general RMCP manual can be obtained via TechSupport@newtec.eu.
- Page 10 User Manual for AZ430 WAN Satellite Modem About this Manual Options AZ 430 WANSatellite Modem Order n° Default Configuration Order n° DVB modem with HSSI interfaces, L-band (950-2150 MHz) input, SNMP AZ430 HSSI interface rate: up to 52 Mbit/s Output interface mod: L-band (950-1750 MHz) Modulation: Q/8PSK Max.
- Page 11 User Manual for AZ430 WAN Satellite Modem About this Manual Feedback Newtec encourages your comments concerning this document. We are committed to providing documentation that meets your needs. Please send any comments by contacting us at documentation@newtec.eu. Please include document and any comment, error found or suggestion for improvement you have regarding this document.
-
Page 12: Table Of Contents
User Manual for AZ430 WAN Satellite Modem Table of Contents TABLE OF CONTENTS Table of Contents ....................xi Introduction ....................1 Short Description .....................1 Contents of the Document ................2 Installation ......................3 Rack Mounting ....................3 Power Supply....................3 2.2.1 AC Power Supply ..................3 2.2.2 Cable Distribution System ................3... - Page 13 User Manual for AZ430 WAN Satellite Modem Table of Contents Features ......................21 The Noise and Distortion Estimator (NoDE)..........21 6.1.1 Introduction....................21 6.1.2 How does NoDE work ................21 Equalink ......................24 Demodulator Statistics...................25 6.3.1 FEC-rate and mod ..................25 6.3.2 Frame type ....................25 6.3.3 Pilots ......................25...
-
Page 14: Introduction
Equalink™ provides an additional link margin improvement of up to 2,5dB. On the receive side, the AZ430 has a dual L-band input (950-2150 MHz). The active input is selected by the user and can provide DC power and frequency band selection signals compatible with most professional and commercial LNBs. -
Page 15: Contents Of The Document
User Manual for AZ430 WAN Satellite Modem Introduction Contents of the Document • Chapter 2 describes the physical installation parameters. • Chapter 3 describes the physical interfaces and the front and back panel connections of the modem. • Chapter 4 describes how to manage the modem. -
Page 16: Installation
User Manual for AZ430 WAN Satellite Modem Installation 2 INSTALLATION Rack Mounting The equipment is designed to operate in a 19-inch rack system conform to IEC 60297. When mounted in a standard 19-inch equipment rack, make sure you sustain it with L-profiles. Do not fix the modem with four front panel screws only, since this will damage the modem and could result in self injury. -
Page 17: Technical Earthing
User Manual for AZ430 WAN Satellite Modem Installation 2.2.3 Technical Earthing On the rear panel of the equipment a technical earthing is available (an unmarked terminal on the right side of the equipment). It is provided to: • Ensure that all equipment chassis fixed within a rack are at the same technical earth potential. -
Page 18: Physical Description
User Manual for AZ430 WAN Satellite Modem Physical Description 3 PHYSICAL DESCRIPTION Front Panel Description Figure 1 – AZ430 Telco Satellite Modem 3.1.1 Display The display consists of a 2 x 40 characters LCD screen. The top row indicates the path in the menu structure while the bottom row displays the selected item. -
Page 19: Leds
User Manual for AZ430 WAN Satellite Modem Physical Description 3.1.3 LEDs Figure 3 – Modem LEDs Demod Lock: Demodulator is locked to the carrier signal. green PLSync. BBSync Demodulator lock led Alarm Alarm OK (No Alarm) Alarm Blinking OK (No Alarm) -
Page 20: Back Panel Description
The back panel consists of several hardware modules. In the following paragraphs these modules are described in more detail. Figure 4 -AZ430 Telco Satellite Modem back panel connections 3.2.1 PSU, M&C Interface and External 10.0 MHz Reference Input Ref. - Page 21 Contact Closure Alarm Outputs Figure 7 - Contact Closure Alarm Outputs You can use the contact closure alarm to drive external alarm indicators (sirens, flashlight…) or to connect to a redundancy switching systems like the Newtec AZ2xx series. version 1.0...
- Page 22 User Manual for AZ430 WAN Satellite Modem Physical Description Figure 8 - Contact Closure Alarm Connections Pin 2 and 4 are either floating or tied to chassis earthing. 10.0 MHz Reference Input This input is used when you need a reference with enhanced stability or when you need several devices to be synchronised to the same clock source.
-
Page 23: Telco Back Panel Interface
User Manual for AZ430 WAN Satellite Modem Physical Description 3.2.2 Telco Back Panel Interface Figure 9 – Telco Back Panel Interface The telco interface contains two independent G.703 interfaces for 75 Ohm coaxial cable connections. Each interface can be equipped with a G.703 plug-in module for all current rates. -
Page 24: L-Band Modulator Back Panel Interface
User Manual for AZ430 WAN Satellite Modem Physical Description 3.2.3 L-Band Modulator Back Panel Interface Figure 10 – L-Band Modulator Back Panel Interface • Ext. In: External L-band in; if equipped with a RF up-converter. • Mon. out: L-band monitoring output from the modulator. -
Page 25: How To Manage
User Manual for AZ430 WAN Satellite Modem How to Manage 4 HOW TO MANAGE Graphical User Interface (GUI) 4.1.1 How to Connect 4.1.1.1 Cabling Use a crossed network cable for a direct connection between the Ethernet port of the modem to the Ethernet port of a computer. In case that connection to the modem is done via a HUB or switch, straight network cables are used. - Page 26 User Manual for AZ430 WAN Satellite Modem How to Manage By default, the IP address of all Newtec devices is 10.0.0.1. /Unit/Setup/Ethernet Device IP address: 010.000.000.001 In this mode, click on the left side of the screen to get an overview of all the parameters in the modem.
- Page 27 User Manual for AZ430 WAN Satellite Modem How to Manage The GUI displays seven main menus: • Home: this menu allows you to remotely monitor and control all the parameters of the modem through the web-interface. You can also change all the parameters that can be changed through the keypad here.
-
Page 28: Front Panel
User Manual for AZ430 WAN Satellite Modem How to Manage Front Panel The first line of the display contains your current location in the menu tree of the modem. The second line contains the parameter name and its value. AZ128/Unit/Control Device sleep mode: operational version 1.0... -
Page 29: Rmcp
You can download our RMCP loader tool for free from www.newtec.eu> Downloads. The RMCP manual explains how Newtec devices can be remotely monitored and controlled via the serial port or via Ethernet. A copy of a separate general RMCP manual can be obtained via TechSupport@newtec.eu. -
Page 30: Serial Interface And Line Settings
User Manual for AZ430 WAN Satellite Modem How to Manage When using RS232, use a null-modem cable with the following layout: Modem Signal 9 Pin D-types 9 Pin D-types Table 3 - RS232 Cable Pin Layout 4.3.3 Serial Interface and Line Settings The main line settings for this serial interface are: •... -
Page 31: Protocol
250 ms. If the message is not completed within this time, it is discarded. SNMP The Newtec MIB allows full monitor and control over the complete device using any SNMP browser (HP-OpenView, NetworkView). We support the basic standard MIB (monitor and control of IP interface, versions of the software …) and above that we... -
Page 32: Block Diagram
User Manual for AZ430 WAN Satellite Modem Block Diagram 5 BLOCK DIAGRAM HSSI Figure 12 - Block Diagram for the IF-band AZ430 Modem. version 1.0 SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS... - Page 33 Filter & demux BB De-framing CRC-8 buffer 22KHz regenerator IFL IN 1 LDPC Tuner Demodulator PL Deframing BCH decoding Descrambler decoding Descrambler IFL IN 2 Figure 13 - Block Diagram for the L-band Type AZ430 Modem version 1.0 SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS...
-
Page 34: Features
User Manual for AZ430 WAN Satellite Modem Features 6 FEATURES The Noise and Distortion Estimator (NoDE) 6.1.1 Introduction NoDE (Noise & Distortion Estimator) simplifies ground station operation activities and enables an efficient usage of transponders. NoDE is a unique and innovative tool that simplifies ground station operation activities by providing a means to monitor the quality of the satellite link. - Page 35 User Manual for AZ430 WAN Satellite Modem Features It is commonly accepted that a transmission is considered as error-free when the PER (Packet Error Rate) at the reception side is below 10 . For each DVB-S2 modcod, as shown in Figure 14, a minimum value (Es/No) guarantees quasi error free transmission.
- Page 36 User Manual for AZ430 WAN Satellite Modem Features By observing the evolution of (Es/No) + Δ functioning in a variation of the uplink power, NoDE can also help the operator to find the optimal operational point of the transponder without interrupting the transmission.
-
Page 37: Equalink
The Equalink™ concept effectively optimises satellite link performance by counteracting these effects. Newtec DVB-S2 Modems equipped with the Equalink™ feature contain, both linear and non-linear predistortion functions which can be individually enabled /disabled. Please refer to the Equalink™ User Manual for a full description of this feature version 1.0... -
Page 38: Demodulator Statistics
User Manual for AZ430 WAN Satellite Modem Features Demodulator Statistics The demodulator statistics shows a number of monitoring parameters of the received carrier for each stream present in that received carrier in case of DVB-S2. Figure 17 – Screenshot of the Demodulator Statistics overview. -
Page 39: Channel Quality Estimation
User Manual for AZ430 WAN Satellite Modem Features 6.3.6 Channel quality estimation The channel quality estimation displays the Es/No of the modulated symbols for each of the DVB-S2 streams in the received carrier. It differs from the total carrier Es/No which only looks at the Physical Layer Headers (which are modulated in a kind of BPSK modulation). -
Page 40: Appendix A - Technical Specifications
User Manual for AZ430 WAN Satellite Modem Appendix A – Technical Specifications APPENDIX A – TECHNICAL SPECIFICATIONS Data interface HSSI interface • Connector sub-D (F) • Rate 0.05 - 110 Mbit/s • Output levels ECL-10 kH (330 Ω ; -5 V) •... - Page 41 User Manual for AZ430 WAN Satellite Modem Appendix A – Technical Specifications Modulator interface L-band output (default): • Connector SMA (F), 50 ohms • Level -50/-7 dBm (+/- 2dB) • Frequency 950 - 1750 MHz (50 Hz steps) • Return loss >...
- Page 42 User Manual for AZ430 WAN Satellite Modem Appendix A – Technical Specifications Demodulator interface Dual L-band input (default) • Connector 2 x F-type (F), 75 ohms • Return loss > 7 dB • Frequency 950 - 2150 MHz • Level -65/-25dBm •...
- Page 43 User Manual for AZ430 WAN Satellite Modem Appendix A – Technical Specifications DVB-S2 performances at PER 1E-5 Short Normal Frames Frames < 15 Mbaud < 45 Mbaud Config Es/No Es/No QPSK- 1/3 -0.6 -0.7 QPSK- 2/5 QPSK- 1/2 QPSK- 3/5...
- Page 44 User Manual for AZ430 WAN Satellite Modem Appendix A – Technical Specifications Generic Monitor and control interfaces • Web server GUI (HTTP) via web browser • Diagnostics report, alarm log (HTTP) • RMCP over TCP-IP/UDP and RS232/RS485 • SNMP v.2c/MIB Alarm interface •...
-
Page 45: Appendix B - User Defined Menu
Choose AZ430 > Unit > Setup > User menu and click OK. AZ430/Unit/Setup User menu: <press OK, ESC when done> Choose AZ430 > Unit > Setup > User menu and click OK. This brings up the first item from the AZ430 > Control menu: AZ430/Control not present <example parameter>... -
Page 46: Appendix C - List Of Abbreviations
User Manual for AZ430 WAN Satellite Modem Appendix C – List of Abbreviations APPENDIX C – LIST OF ABBREVIATIONS Acronym Definition Alternating Current Adjacent Channel Interference APSK Amplitude and Phase Shift Keying Asynchronous Serial Interface Base Band Bit Error Rate/Ratio... - Page 47 User Manual for AZ430 WAN Satellite Modem Appendix C – List of Abbreviations Acronym Definition Graphical User Interface High Power Amplifier (used in SNG terminals) HSSI High Speed Serial Interface HTML HyperText Mark-up Language (used by World-Wide Web Docs) HTTP...
- Page 48 User Manual for AZ430 WAN Satellite Modem Appendix C – List of Abbreviations Acronym Definition RMCP Remote Monitor and Control Protocol SNMP Simple Network Management Protocol Transfer Orbit (satellites) Volt-Ampere version 1.0 SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS...
