User Manual
for
AZ420 Telco Satellite Modem
version 2.0
SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AZ420 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Newtec AZ420

Summary of Contents for Newtec AZ420

  • Page 1 User Manual AZ420 Telco Satellite Modem version 2.0 SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS...
  • Page 2 User Manual for AZ420 Telco Satellite Modem © 2010 Newtec Cy N.V.. The material contained in this document is confidential and intended for use only by parties authorised by Newtec. All Rights Reserved. No part of this document may be photocopied, reproduced,...

  • Page 3: Compliancy Statements

    User Manual for AZ420 Telco Satellite Modem Compliancy Statements COMPLIANCY STATEMENTS TO WHOM IT MAY CONCERN EC DECLARATION OF CONFORMITY Newtec Cy N.V. Declare that the following product: Product number: with type identifier: NTC/2210 (IF) and NTC/2215 (L-Band) to which this declaration relates is in conformity with the essential requirements of European Union Directive 1999/5/EC Radio and Telecommunication Terminal Equipment Directive Essential Requirement 3.1(a), 3.1 (b), 3.2.
  • Page 4 User Manual for AZ420 Telco Satellite Modem Compliancy Statements TO WHOM IT MAY CONCERN Restriction of Hazardous Substances Directive (RoHS) (Directive 2002/95/EC) The undersigned hereby confirms the following statement: We hereby declare that this equipment is compliant to the RoHS Directive 2002/95/EC.

  • Page 5: Safety Regulations

    Only qualified personnel who are aware of hazards involved may adjust, maintain and repair the exposed equipment. The AZ420 Telco Satellite Modem has no operator serviceable parts inside. Refer servicing to qualified personnel. To prevent electrical shock, do not remove covers.
  • Page 6 User Manual for AZ420 Telco Satellite Modem Safety Regulations Additional safety requirements for Finland, Norway and Sweden Telecommunication connections and cable distribution system. Special conditions apply to the use of this equipment in Finland, Sweden and Norway due to different earthing arrangements in these countries.
  • Page 7 User Manual for AZ420 Telco Satellite Modem Safety Regulations Environmental Operating the equipment in an environment other than that stated in the specifications also invalidates the safety compliance. Do not use the equipment in an environment in which the unit is exposed to: •...

  • Page 8: Maintenance

    Newtec and in line with good practice. The warranty does not apply to items, normally consumed in operation, or which have a normal lifetime inherently shorter than the warranty stated above, such as, without limitation, fuses or lamps.

  • Page 9: About This Manual

    User Manual for AZ420 Telco Satellite Modem About this Manual ABOUT THIS MANUAL This document provides a quick overview on how to easily set up the modem for the most common use cases. This document is intended to help you: •...

  • Page 10: Related Documentation

    User Manual details the linear and non-linear pre-distortion capabilities. • The RMCP manual explains how Newtec devices can be remotely monitored and controlled via the serial port or via Ethernet. Device leaflet (see http://www.newtec.eu) Request a RMCP and SNMP manual via the Newtec Service Desk tool: >...
  • Page 11 User Manual for AZ420 Telco Satellite Modem About this Manual Options version 2.0 SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS...
  • Page 12 User Manual for AZ420 Telco Satellite Modem About this Manual Feedback Newtec encourages your comments concerning this document. We are committed to providing documentation that meets your needs. Please send any comments by contacting us at documentation@newtec.eu. Please include document and any comment, error found or suggestion for improvement you have regarding this document.

  • Page 13: Table Of Contents

    User Manual for AZ420 Telco Satellite Modem Table of Contents TABLE OF CONTENTS Compliancy Statements ..................ii Safety Regulations ....................iv Maintenance ......................vii Standard Warranty ....................vii Care Pack ........................ vii About this Manual ....................viii Table of Contents ....................xii Introduction....................... 1 Short Description ....................
  • Page 14 User Manual for AZ420 Telco Satellite Modem Table of Contents 4.3.1 Cabling ......................21 4.3.2 Settings ......................21 Management using the Serial Interface ............22 4.4.1 Cabling ......................22 4.4.2 Serial Port Settings ..................22 4.4.3 Serial Interface and Line Settings ..............23 Graphical User Interface Description ............23 Remote Monitoring and Control Protocol .............25...
  • Page 15 User Manual for AZ420 Telco Satellite Modem Table of Contents Appendix A – User Defined Menu ................40 Appendix B – Technical Specifications ...............41 Appendix C – Details GR-01 and GR-02 ..............47 Appendix D – How to Mix Normal and Short Frames ........48 Appendix E –...

  • Page 16: Introduction

    1 INTRODUCTION Short Description The AZ420 is a state-of-the-art satellite modem designed for fixed rate telco, voice and data applications over satellite in full compliance with the DVB standards. The AZ420 connects directly with terrestrial data and voice networks through a standard G.703 interface.

  • Page 17: Contents Of The Document

    User Manual for AZ420 Telco Satellite Modem Introduction Contents of the Document • Chapter 2 describes the physical installation parameters; • Chapter 3 describes the physical interfaces and the front and back panel connections of the modem; • Chapter 4 describes how to manage the Modem;...

  • Page 18: Installation

    User Manual for AZ420 Telco Satellite Modem Installation 2 INSTALLATION Rack Mounting The equipment is designed to operate in a 19-inch rack system conform to IEC 60297. When mounted in a standard 19-inch equipment rack, make sure you sustain it with L-profiles. Do not fix the modem with four front panel screws only, since this will damage the modem and could result in self injury.

  • Page 19: Cable Distribution System

    User Manual for AZ420 Telco Satellite Modem Installation Cable Distribution System Install the equipment in accordance with the applicable provisions of NEC Article 810 for US and with CEC section 54 for Canada. Before connecting the coax to the equipment, make sure that the equipment is properly earthed. The screen of the used coax cable should be grounded according to the local regulations.

  • Page 20: Physical Description

    User Manual for AZ420 Telco Satellite Modem Physical Description 3 PHYSICAL DESCRIPTION Front Panel Description Figure 1 – AZ420 Telco Satellite Modem 3.1.1 Display The display consists of a 2 x 40 characters LCD screen. The top row indicates the path in the menu structure while the bottom row displays the selected item.

  • Page 21: Leds

    User Manual for AZ420 Telco Satellite Modem Physical Description 3.1.3 LEDs Figure 3 – Modem LEDs Demod Lock: green Demodulator is locked to the carrier signal. PLSync. BBSync Demodulator lock led Alarm Alarm OK (No Alarm) Alarm Blinking OK (No Alarm)

  • Page 22: Back Panel Description

    Physical Description Back Panel Description The back panel consists of several modules depending on the hardware that is installed. Figure 4 -AZ420 Telco Satellite Modem back panel connections 3.2.1 PSU, M&C Interface and External 10.0 MHz Reference Input Ref. In M&C RS232/485...
  • Page 23 Figure 7 - Contact closure alarm outputs You can use the contact closure alarm to drive external alarm indicators (sirens, flashlight…) or to connect to a redundancy switching systems like the Newtec AZ2xx series. Figure 8 - Contact closure alarm connections Pin 2 and 4 are either floating or tied to chassis earthing.
  • Page 24 RMCP address of the device (that is present in an RMCP command). Request a RMCP and SNMP manual via the Newtec Service Desk tool: > Browse to http://customersupport.newtec.eu...

  • Page 25: Sub Back Panel Descriptions

    User Manual for AZ420 Telco Satellite Modem Physical Description 3.2.2 Sub Back Panel Descriptions In this section the different sub back panels for the device are listed. Depending on the hardware that is ordered a combination of sub back panels are used.
  • Page 26 User Manual for AZ420 Telco Satellite Modem Physical Description Back Panel 02 / Description Connector 1. EXT L IN 2. MON OUT 3. REF OUT 4. MOD OUT version 2.0 SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS...
  • Page 27 User Manual for AZ420 Telco Satellite Modem Physical Description Connector Back Panel 03 / Description Connector 1. MOD OUT 2. MON OUT 3. REF OUT version 2.0 SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS...
  • Page 28 User Manual for AZ420 Telco Satellite Modem Physical Description Back Panel 04 / Description Connector 1. L-BAND IN 1 2. COMB/SPLITTER IN 2 3. REF OUT 4. L_BAND COND / IFL IN (OUT) 5. L_BAND COND / IFL OUT(IN) 6. IFL OUT 1 7.
  • Page 29 User Manual for AZ420 Telco Satellite Modem Physical Description Back Panel 05 / Description Connector 1. IFL 1 IN 2. IFL 2 IN 3. REF OUT 4. IF IN version 2.0 SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS...
  • Page 30 User Manual for AZ420 Telco Satellite Modem Physical Description Connector Back Panel 06 / Description Connector 1. IFL IN (OUT) 2. IFL OUT (IN) version 2.0 SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS...
  • Page 31 User Manual for AZ420 Telco Satellite Modem Physical Description Back Panel 07 / Description Connector 1. REF OUT 2. IF IN 3. IFL IN version 2.0 SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS...

  • Page 32: Back Panel Interfaces

    User Manual for AZ420 Telco Satellite Modem Physical Description 3.2.3 Back Panel Interfaces The sub back panels used per ordering option is listed in the following tables. We refer to page ‘x’ for the Options for ordering information. We refer to section Sub Back Panel Descriptions 3.2.2 for the description of the different sub back panels.

  • Page 33: How To Manage

    User Manual for AZ420 Telco Satellite Modem How to manage 4 HOW TO MANAGE This section explains how the AZ420 Telco Satellite Modem can be configured and how the parameters in the device are ordered and managed according to your needs.
  • Page 34 User Manual for AZ420 Telco Satellite Modem How to manage Figure 9 - Menu Tree of the AZ420 version 2.0 SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS...

  • Page 35: Front Panel Display

    User Manual for AZ420 Telco Satellite Modem How to manage Front Panel Display 4.2.1 Normal Display The first line of the display contains your current location in the menu tree of the demodulator. The second line contains the parameter name and its value.

  • Page 36: Management Using The Ethernet Interface

    User Manual for AZ420 Telco Satellite Modem How to manage Management using the Ethernet Interface 4.3.1 Cabling Use a crossed network cable for a direct connection between the Ethernet port of the demodulator to the Ethernet port of a computer. In case connection to the demodulator is done via a hub or switch, straight network cables are used.

  • Page 37: Management Using The Serial Interface

    User Manual for AZ420 Telco Satellite Modem How to manage Management using the Serial Interface 4.4.1 Cabling The cable to connect via the Serial Interface must comply with the pin configurations as described in section 3.2 4.4.2 Serial Port Settings The demodulator is set to RS485 by factory default.

  • Page 38: Serial Interface And Line Settings

    Type the following address in the address bar: http://ip_address_device. You can find the IP address device in the following menu: /Unit/Setup/Ethernet settings on the front panel of the device. By default, the IP address of all Newtec devices is 10.0.0.1.
  • Page 39 User Manual for AZ420 Telco Satellite Modem How to manage Log in with the user name and password that is defined in the following menu >> Unit >> Setup >> Web interface menu. By default the login credentials <root> <root> are used.

  • Page 40: Remote Monitoring And Control Protocol

    You can download our RMCP loader tool for free from the webpage www.newtec.eu. The RMCP manual explains how Newtec devices can be remotely monitored and controlled via the serial port or via Ethernet. Request a RMCP manual via the Newtec Service Desk tool: >...

  • Page 41: Protocol

    The total transmit time of a complete message may not exceed 250ms. If the message is not completed within this time, it is discarded. The RMCP manual explains how Newtec devices can be remotely monitored and controlled via the serial port or via Ethernet.

  • Page 42: Simple Network Management Protocol (Snmp)

    How to manage Simple Network Management Protocol (SNMP) The Newtec MIB allows full monitor and control over the complete device using any SNMP browser (HP-OpenView, NetworkView). We support the basic standard MIB (monitor and control of IP interface, versions of the software …) and above that we have a full proprietary MIB, which contains all the OIDs needed to control the device.

  • Page 43: Block Diagram

    • Alarm Output; • Remote Monitoring and Control over LAN or RS232/RS485; • Front Panel. For more information we refer to section 3. Figure 10 - Block diagram for the L-band type AZ420 Modem version 2.0 SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS...

  • Page 44: Modulator Functionality

    Block Diagram Modulator Functionality In its default configuration, the AZ420 supports E1 rates. The support of E2, T2, E3 and T3/DS3 rates are available as configuration option. It is also possible to configure the modem with a secondary G.703 input/output, for the implementation of a redundant configuration or to allow the modem to be compatible with two different transmission rates.

  • Page 45: Demodulator Functionality

    Block Diagram Demodulator Functionality In its default configuration the AZ420 has a dual L-band input (950-2150MHz). The active L-Band input is selected by the user and can provide DC power and frequency band selection signals compatible with most professional and commercial LNBs.

  • Page 46: Features

    User Manual for AZ420 Telco Satellite Modem Features 6 FEATURES Clocking Parameters and Schemes 6.1.1 Clock Selection Possibilities Figure 11 - Clock Selection Possibilities There are three Master Clock Selection possibilities: • Internal clock; • External G703; • 10Mhz input (optional).

  • Page 47: Deframer Buffer (Doppler Buffer)

    User Manual for AZ420 Telco Satellite Modem Features Output Clock Selection : • Internal; • External G703; • Clock from satellite. The output clock selection determines the clock source that is used to clock the data on the G703 TX interface. The system runs on its own internal clock by selecting “internal”.

  • Page 48: Typical Application

    User Manual for AZ420 Telco Satellite Modem Features In case of clock slaving via satellite the buffer must be twice this value because the transmit clock has also Doppler shift. The internal clock is normally only used when the master clock is set to a very accurate (external) reference and is very close to the TX clock.

  • Page 49: The Noise And Distortion Estimator (Node)

    User Manual for AZ420 Telco Satellite Modem Features The Noise and Distortion Estimator (NoDE) 6.2.1 Introduction NoDE (Noise & Distortion Estimator) simplifies ground station operation activities and enables an efficient usage of transponders. NoDE is a unique and innovative tool that simplifies ground station operation activities by providing a means to monitor the quality of the satellite link.
  • Page 50 User Manual for AZ420 Telco Satellite Modem Features Figure 14 - LME – Linear Environment In a linear environment, as described in Figure 14, the Link Margin Estimates (LME) provided with or without NoDE are identical. They correspond with the...

  • Page 51: Equalink

    The Equalink™ concept effectively optimises satellite link performance by counteracting these effects. Newtec DVB-S2 Modems equipped with the Equalink™ feature contain, both linear and non-linear predistortion functions which can be individually enabled /disabled. Please refer to the Equalink™ User Manual for a full description of this feature version 2.0...

  • Page 52: Demodulator Statistics

    User Manual for AZ420 Telco Satellite Modem Features Demodulator Statistics The demodulator statistics shows a number of monitoring parameters of the received carrier for each stream present in that received carrier in case of DVB-S2. Figure 16 – Screenshot of the Demodulator Statistics Overview 6.4.1...

  • Page 53: Data Esno Clipping Info

    User Manual for AZ420 Telco Satellite Modem Features 6.4.6 Data EsNo clipping info Data EsNo clipping info indicates a clipped link margin. When reading saturated values for the Es/No estimation, the clipping info will identify the direction of saturation or return equal if the value is within range.

  • Page 54: Link Margin Est

    User Manual for AZ420 Telco Satellite Modem Features 6.4.11 Link margin est. Link margin estimation for each of the DVB-S2 streams in the received carrier. This monitoring parameter indicates how much the Es/No is above the decoding threshold. It is a measure for the number of dBs of fading that is possible on the link before the demodulator is not able to decode the received signal anymore.

  • Page 55: Appendix A - User Defined Menu

     Choose AZ420 > Unit > Setup > User menu and click OK. AZ420/Unit/Setup  User menu: <press OK, ESC when done>   Choose AZ420 > Unit > Setup > User menu and click OK. This brings up the first item from the AZ420 > Control menu: AZ420/Control not present ...

  • Page 56: Appendix B - Technical Specifications

    User Manual for AZ420 Telco Satellite Modem Appendix B – Technical Specifications APPENDIX B – TECHNICAL SPECIFICATIONS Input/output interface G.703 input/output: • Connector : BNC (F) • Impedance : 75 ohms • Rate : 2.048 ; 6.312 ; 8.448; 34.368 ; 44.736 Mbps Clock stability –...
  • Page 57 User Manual for AZ420 Telco Satellite Modem Appendix B – Technical Specifications Modulation and Demodulation Supported modulation schemes and FEC • DVB-S/DSNG: Outer/Inner FEC: Reed Solomon /Viterbi MODCODs: ­ QPSK: 1/2, 2/3, 3/4, 5/6, 7/8 ­ 8PSK: 2/3, 5/6, 8/9 ­...
  • Page 58 User Manual for AZ420 Telco Satellite Modem Appendix B – Technical Specifications Frame length • DVB-S2 Short Frames 16 200 bit • DVB-S2 Normal Frames 64 800 bit • DVB-S/DSNG 188 bytes Roll-off factor • 20 % - 25 % - 35 %...
  • Page 59 User Manual for AZ420 Telco Satellite Modem Appendix B – Technical Specifications IF-band input (optional, replaces one L-band input) • Connector BNC (F) - 75 ohms • Return loss > 15 dB • Level -55 to -15 dBm • Frequency 50 - 180 MHz •...
  • Page 60 User Manual for AZ420 Telco Satellite Modem Appendix B – Technical Specifications Short Normal Frames Frames 8PSK- 8/9 11.4 11.1 8PSK- 9/10 11.3 16APSK- 2/3 16APSK- 3/4 10.9 10.5 16APSK- 4/5 11.6 11.5 16APSK- 5/6 12.4 12.1 16APSK- 8/9 13.6 13.3...
  • Page 61 User Manual for AZ420 Telco Satellite Modem Appendix B – Technical Specifications Internal Reference frequency High Stability (optional) • Stability ±5x10 over 0°C to 70°C • Ageing: ± 15 ppb/day ± 300 ppb/year Very High Stability (optional) • Stability: ±2x10 over 0°C to 65°C •...

  • Page 62: Appendix C - Details Gr-01 And Gr-02

    User Manual for AZ420 Telco Satellite Modem Appendix C – Details GR-01 and GR-02 APPENDIX C – DETAILS GR-01 AND GR-02 Specifications of option GR-01 - High Stability 10MHz reference In/Out Stability: +/-5x10exp-8 over 0°C to 70°C Warm-up time: 5 min (+/-100 ppb)

  • Page 63: Appendix D - How To Mix Normal And Short Frames

    User Manual for AZ420 Telco Satellite Modem Appendix D – How to Mix Normal and Short Frames APPENDIX D – HOW TO MIX NORMAL AND SHORT FRAMES Introduction This section will give some more information on the limitations when mixing normal and short frames.
  • Page 64 User Manual for AZ420 Telco Satellite Modem Appendix D – How to Mix Normal and Short Frames Short & Normal = Using short frames mixed with normal frames. Normal & Short = Using normal frames mixed with short frames. Conclusion As a general rule, we can say that it is recommended to use normal frames.

  • Page 65: Appendix E - Abbreviations

    User Manual for AZ420 Telco Satellite Modem Appendix E – Abbreviations APPENDIX E – ABBREVIATIONS Acronym Definition Adjacent Channel Interference APSK Amplitude and Phase Shift Keying Asynchronous Serial Interface Base Band Bit Error Rate/Ratio Bayonet (Neill Concelman) Connector (for coaxial cable)
  • Page 66 User Manual for AZ420 Telco Satellite Modem Appendix E – Abbreviations Acronym Definition Intermediate Frequency Inter Facility Link Internet Protocol Information Technology ITU-T International Telecommunication Union Telecom Standard Sector Local Area Network Liquid Crystal Display Link Margin Estimator Low noise block downconverter Least Significant Bit (in digital coding) M&C...
  • Page 67 User Manual for AZ420 Telco Satellite Modem Appendix E – Abbreviations Acronym Definition SAME Spectrum Management Agency SNMP Simple Network Management Protocol Transmit version 2.0 SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS...
