Viking Range 5 Series Installation, Use & Care Manual
Outdoor warming drawer/ convenience center
Hide thumbs
Also See for 5 Series:
- Use & care / installation manual (48 pages) ,
- Installation instructions manual (48 pages) ,
- Installation, use & care manual (44 pages)
Subscribe to Our Youtube Channel
Related Manuals for Viking Range 5 Series
Summary of Contents for Viking Range 5 Series
- Page 1 Installation / Use & Care MANUAL 5 SERIES Outdoor Warming Drawer/ Convenience Center VQEWD5301 VQEWD5421...
-
Page 2: Table Of Contents
Table of Contents Warnings __________________________________________________________________________ 3 Installation ________________________________________________________________________ 5 Dimensions VQEWD5301 _________________________________________________________ 6 Dimensions VQEWD5421 _________________________________________________________ 8 Important Safety Warnings __________________________________________________________ 10 Before Using your Appliance _________________________________________________________ 11 Temperature Controls ______________________________________________________________ 11 Heat Light ON _________________________________________________________________ 11 Moisture Vent Control __________________________________________________________ 11 Cleaning and Maintenance __________________________________________________________ 12 Troubleshooting ___________________________________________________________________ 12 Service Information ________________________________________________________________ 13... -
Page 3: Warnings
Warnings Warning and Important Safety Instructions appearing in this manual are not meant to cover all possible conditions and situations that may occur. Common sense, caution, and care must be exercised when installing, maintaining, or operating the appliance. ALWAYS contact the manufacturer about problems or conditions you do not understand. Recognize Safety Symbols, Words, Labels DANGER Hazards or unsafe practices which WILL result in... - Page 4 Warnings WARNING WARNING NEVER use this appliance as a space heater to heat or BURN OR ELECTRICAL SHOCK HAZARD warm the room. Doing so may result in carbon monoxide Make sure all controls are OFF and drawer is poisoning and overheating of the drawer. COOL before cleaning.
-
Page 5: Installation
Installation • Be sure that the warming drawer is properly grounded and installed by a qualifi ed technician. The electrical cord has a 3 prong plug. Do not cut any of the prongs. • Make sure that the island is free of cracks that would allow water or other liquids to get into the electrical controls. •... -
Page 6: Dimensions Vqewd5301
VQEWD5301 Dimensions TOP VIEW 21-1/8” (53.7 cm) 20” (50.8cm) 28-1/4” (71.8 cm) 30” (76.2 cm) 23-5/8” (60.0 cm) 4-5/8” (11.7 cm) SIDE VIEW 20-1/2” (52.1 cm) 21-1/8” (53.7 cm) 17-1/2” (44.5 cm) 20” (50.8 cm) 15/16” (0.9 cm) 9-3/4” (24.8 cm) 15/16”... - Page 7 VQEWD5301 Cutout Dimensions VQEWD5301 Support Beams Cutout 28-1/2 Width (W) (72.4 cm) Cutout 20-1/2” Depth (D) (52.1 cm) Cutout 10” Height (H) (25.4cm) 11-1/2” (29.2 cm) Apply weather proof sealant along the edges of the warmer Installation -Provide a 10” x 28 ½” cutout to the front of the island. -Provide support beams using metal studs.
-
Page 8: Dimensions Vqewd5421
VQEWD5421 Dimensions TOP VIEW 26-3/16” (66.5 cm) 24-9/16” (62.4 cm) 41-3/4” 40-1/8” (106.0 cm) (101.9 cm) 26-3/16” (66.5 cm) SIDE VIEW 17-1/2” (44.5 cm) 24-9/16” (62.4 cm) 19” (48.3 cm) FRONT VIEW 41-3/4” (106.0 cm) 11-1/2” (29.2 cm) 21” (53.3 cm) 9-5/16”... - Page 9 VQEWD5421 Cutout Dimensions VQEWD5421 Cutout 40-1/4” Width (W) (102.2 cm) Cutout 24-1/2” Depth (D) (62.2 cm) Cutout 19-3/8” Height (H) (49.2) 21” (53.3 cm) Installation -Provide a 19 3/8” x 40 ¼” cutout to the front of the island. -Provide support beams using metal studs. -Pull the drawer out of the drawer casing to gain access on the mounting holder at the front of the casing.
-
Page 10: Important Safety Warnings
Important Safety Warnings WARNING If the information in this manual is not followed exactly, a fi re or explosion may result causing property damage, personal injury or death. About your Appliance •Do not touch the heating elements or interior surface of the drawer while it is in use. Use handles or knobs. •Do not store fl ammable materials in drawer. -
Page 11: Before Using Your Appliance
Before Using Your Appliance All products are wiped clean with solvents at the factory to remove any visible signs of dirt, oil, and grease which may have remained from the manufacturing process. Before using, clean the drawer thoroughly with hot, soapy water. There may be some burn off and odors on fi rst use of the appliance—this is normal. -
Page 12: Cleaning And Maintenance
Cleaning and Maintenance WARNING To prevent burns, do not remove pans while hot. Make sure drawer is cool before cleanng. Any piece of equipment works better and lasts longer when maintained properly and kept clean. Cooking equipment is no exception. Your warming drawer must be kept clean and maintained properly. -
Page 13: Service Information
Clearly describe the problem that you are having. If you are unable to obtain the name of an authorized service agency, or if you continue to have service problems, contact Viking Range, LLC at1-888-845-4641, or write to: Viking Range, LLC... -
Page 14: Outdoor Warranty
Outdoor products and all of their component parts, except as detailed below*, are warranted to be free from defective materials or workmanship in residential housed hold use for a period of one (1) year from the date of original retail purchase. Viking Range, warrantor, agrees to repair or replace at its option, any part which fails or is found to be defective during the warranty period. - Page 16 Viking Range, LLC 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-845-4641 or visit our web site at vikingrange.com 068960-000A EN (022820)
