Installation/
Use & Care
MANUAL
5 SERIES
Outdoor Gas Grills
VQGI5301, VQGI5361, VQGI5421, VQGI5541
VQGFS5301, VQGFS5361, VQGFS5421, VQGFS5541

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Viking Range 5 Series

Summary of Contents for Viking Range 5 Series

  • Page 1 Installation/ Use & Care MANUAL 5 SERIES Outdoor Gas Grills VQGI5301, VQGI5361, VQGI5421, VQGI5541 VQGFS5301, VQGFS5361, VQGFS5421, VQGFS5541...
  • Page 2 THIS MANUAL MUST REMAIN WITH THE PRODUCT OWNER FOR FUTURE REFERENCE. This product complies with ANSI standard Z21.58/CSA 1.6 latest To obtain replacement parts or service contact: edition and has been tested and approved by Intertek. Viking Range, LLC Preferred Customer Service 111 Front Street Greenwood, Mississippi 38930 Service: (888) 845-4641 INSTALLATION / USE &...
  • Page 3 WARNINGS WARNING READ THIS MANUAL CAREFULLY and completely before using your grill to reduce the risk of: Fire Burn hazard, personal injury or property damage Ruined steaks or other unpleasant cooking experiences Unapproved installation or servicing. THIS PRODUCT IS DESIGNED FOR OUTDOOR USE ONLY. Improper installation, adjustment, alteration, service or mainte- nance can cause property damage, injury or death.
  • Page 4 WARNINGS WARNING Always maintain the required clearances from combustible construction as detailed. The grill is designed for outdoor use only. Never use in a garage, building, shed, breezeway or other enclosed area. This grill shall not be used under any unprotected overhead combustible construction. Gas grills are not design certifi ed for and are not to be installed in or on recreational vehicles, portable trailers, boats or any other moving installation.

  • Page 5: Table Of Contents

    Using the Rotisserie Burner Using the Smoker Box CLEANING YOUR GRILL TROUBLESHOOTING YOUR GRILL Potential Problems CONTACTING CUSTOMER SERVICE VIKING RANGE, LLC OUTDOOR WARRANTY WIRING SCHEMATICS 30 Rotisserie Grill 36 & 42 Rotisserie Grill 54 Rotisserie Grill INSTALLATION / USE & CARE...

  • Page 6: Before You Start

    BEFORE YOU START WARNING Installation into a combustible enclosure requires an insulated jacket accessory. DO NOT REMOVE BRACKET OR INSTALL UNIT without use of the insulated jacket. Doing so may result in a fi re, injury or property damage. Bracket must be removed to complete install with insulated jacket.
  • Page 7 If the grill is to be placed into a combustible enclosure, an approved insulated jacket is necessary and is available only from your Viking Range, LLC dealer. Insulated jackets have been designed and tested specifi cally for your grill. INSTALLATION / USE & CARE...

  • Page 8: Specifications & Installation

    SPECIFICATIONS & INSTALLATION The guides, measurements and dimensions detailed below are designated to assist you with planning your outdoor kitchen. NOTE: Due to continuing product innovation, specifi cations are subject to change without notice. IMPORTANT: Please reference the Care & Use / Installation manual for details on gas plumbing requirements, electrical specifi cations and the proper installation of your outdoor kitchen equipment.
  • Page 9 SPECIFICATIONS & INSTALLATION COUNTER TOP NOTCH DETAIL Only required if island counter top overhangs the face of the island 5” (12.7 cm) 4.5” 3” (11.4 cm) (7.6 cm) MODEL-SPECIFIC BTU OUTPUTS & MAX. RUNS FOR APPLIANCES MODEL-SPECIFIC BTU OUTPUTS MODEL H BURNER (Btu) ROTISSERIE (Btu) PROSEAR™...
  • Page 10 DIMENSIONS VQGI5301 30” 30" 253/16” (76.2 cm) " (64.0 cm) 14½” " (36.8 cm) 1¾” (4.4 cm) " 10½” " 11” (27.9 cm) 11" (26.7 cm) 11" 3" 11” (27.9 cm) 9” (22.9 cm) 9" 21½” 3” (7.6 cm) REAR (54.6 cm) "...
  • Page 11 DIMENSIONS VQGI5361 36” (91.4 cm) 23½” (59.7 cm) 147/8” (37.8 cm) 1¾” (4.4 cm) 97/8” 11” (27.9 cm) (25.1 cm) 11” (27.9 cm) 9” (22.9 cm) 3” (7.6 cm) 19” 2½” (6.4 cm) 11/8” (2.9 cm) (48.3 cm) 227/8” Rear Manifold Location (58.1 cm) 253/8”...
  • Page 12 DIMENSIONS 42” (106.7 cm) 253/16” (64.0 cm) " 14½” " (36.8 cm) 1¾” (4.4 cm) " 10½” 11” (27.9 cm) 9” (22.9 cm) " 11” (27.9 cm) 11" (26.7 cm) 3" 2½” (6.4 cm) 2½” (6.4 cm) 21½” 3” (7.6 cm) Rear Manifold (54.6 cm) Location...
  • Page 13 DIMENSIONS VQGI5541 54” (137.2 cm) 25½” " (64.8 cm) 1413/16” " (37.6 cm) 1¾” (4.4 cm) " 9” (22.9 cm) 11” (27.9 cm) 103/16” " 11” (27.9 cm) 11" (25.9 cm) 2½” (6.4 cm) 2½” (6.4 cm) 3" Rear Manifold 21½”...

  • Page 14: Unpacking & Assembly

    The grill arrives nearly ready to use and requires only minor as- INTERIOR PACKING sembly. Viking Range, LLC uses sturdy tie-down cables and straps to By carefully following the uncrating and unpacking steps, you ensure your grill arrives at your home in the same condition that will improve your fi rst experience with the grill.
  • Page 15 UNPACKING & ASSEMBLY ...continued Heat Shield Removed, Orifi ce/Venturi Position Inside View, Orifi ce all the way into venturi Legs in slot Burner sitting fl at INSTALLATION / USE & CARE...

  • Page 16: Gas Connections

    NATURAL GAS (NAT). It is critical that the gas you use matches that which the Viking Range, LLC recommends that only qualifi ed professionals grill was set up for. You can verify that by checking the rating perform the required plumbing on this product.

  • Page 17: Lp Gas

    GAS CONNECTIONS ...continued For freestanding units using natural gas, using a metal fl ex hose is recommended. WARNING This is available at your local hardware store or from your dealer. Do not change the regulator/hose assembly or use any other assembly than the one supplied with your LP GAS grill.

  • Page 18: Gas Conversion Kits

    Insert the regulator inlet into the cylinder valve and turn the black coupler clockwise until the coupler is hand tight. Do not Gas conversion kits are available from Viking Range to allow over-tighten this connection. the grill to operate on either Natural gas or LPG. These kits To disconnect the coupler, fi rst make sure the main cylinder should be installed by a qualifi ed technician.
  • Page 19 GAS CONNECTIONS ...continued NG AND BULK PROPANE CART INSTALLATION • Shut off the gas supply at the main valve. • Disconnect all plumbing (if already attached) from the grill and he gr r ill and the gas supply valve. • Remove all the fi ttings from the grill manifold. •...

  • Page 20: Electrical Connections

    ELECTRICAL CONNECTIONS WARNING: ELECTRICAL GROUNDING • Product installation must meet local electric codes or, in the absence of local codes, the latest edition of the National Electrical Code ANSI/NFPA No. 70 or the Canadian Electrical Code CGA 1.6b2005. • Use only a Ground Fault Interrupter (GFI) protected circuit with this outdoor cooking gas appliance. •...

  • Page 21: Final Checks

    FINAL CHECKS LEAK TESTING LOW HEAT BURNER ADJUSTMENT FOR MAIN BRASS BURNERS AND SIDE BURNERS ONLY! DO NOT ADJUST THE ROTISSERIE BURNER. DANGER! The main brass burners and side burners on your grill feature an To prevent fi re or explosion hazard, DO NOT smoke or adjustable low setting.
  • Page 22 FINAL CHECKS ...continued BRASS BURNER FLAME/AIR SHUTTER ADJUSTMENT • After the burner cools down, remove it, tighten the air shutter set screw and reinstall the burner, briquette trays and grill The amount of air that enters a burner is controlled by the air racks.

  • Page 23: Checklist Before Each Use

    CHECKLIST BEFORE EACH USE (FOR YOUR SAFETY) • Do you smell gas? If yes, shut off everything and call the gas • If you are using a portable propane cylinder, is it connected company or a qualifi ed plumber to check for leaks, if not and leak tested? If not, check the connection before please continue.
  • Page 24 IMPORTANT SAFETY PRECAUTIONS PLEASE REVIEW THESE IMPORTANT SAFETY PRECAUTIONS BEFORE YOU USE YOUR GRILL. NEVER LEAVE THE GRILL UNATTENDED WHILE COOKING. 12. Never grill without the drip pan in place. Always ensure the drip pan is pushed all the way to the back of the grill. Hot Ensure all tie-down wires have been removed from the grease can leak downward and produce a fi re or explosion.

  • Page 25: Grilling In Windy Conditions

    GRILLING IN WINDY CONDITIONS Outdoor grills create more heat than interior kitchen ranges. • If you suspect the grill is overheating, using an oven mitt, That’s how they sear and grill steaks and other foods. open the front hood. Then adjust the burner control knob to a lower setting.

  • Page 26: Using Your Grill

    ProSear is a trademark of Viking Range LLC PRE-GRILL CHECKLIST BEFORE YOUR FIRST USE • IF YOUR GRILL DOES NOT LIGHT IN 4 TO 5 SECONDS you may need to purge the line.

  • Page 27: Lighting Your Grill

    PRE-GRILL CHECKLIST ...continued BEFORE EACH USE • … you know where the main gas supply shut-off is located. • … the burners are seated properly in the grill. The main Before any use, always make sure that: burners must sit level and fi rmly on the burner mounting •...
  • Page 28 LIGHTING YOUR GRILL ...continued Right-Most Main Burner COLD WEATHER WARNING: The right-most main burner does not feature a manual lighting PROPANE tube. Extremely cold temperatures may cause your To match-light this burner, use the lighting rod to insert a lit ProSear™...

  • Page 29: Basic Grilling

    BASIC GRILLING PRE-HEATING TYPES OF COOKING Pre-heating your grill every time you use it is extremely im- The main brass burners and the ProSear™ burner in your grill are portant. Pre-heating allows the briquettes to properly heat up, capable of creating a range of heat intensities. By varying the providing more even and more consistent cooking results.

  • Page 30: Using The Prosear™ Burner

    ... infrared heat ... to create a higher searing temperature than The result is a restaurant-style fi nish … crisp, fl avorful outside what standard burners can achieve. Viking Range, LLC provides with a tender, juicy inside. the ProSear™ infrared burner.

  • Page 31: Using The Rotisserie Burner

    Rotisserie cooking The Skewer & Forks provides an even The rotisserie can handle large food items up to 50 lbs. You large food items up to 50 lbs. You delivery of heat to should prepare any item and fi rst mount it on the skewer. your foods.

  • Page 32: Using The Smoker Box

    USING THE ROTISSERIE BURNER ...continued Slide the pointed end of the skewer into the motor and rest the food item on the grill then follow the rotisserie lighting other end on the rollers on the other side of the grill. procedure.

  • Page 33: Cleaning Your Grill

    CLEANING YOUR GRILL STAINLESS STEEL SPECIAL NOTE FOR LOCATIONS NEAR POOLS AND COASTAL AREAS: Our products are known for their attractive appearance. We The 304 stainless steel material used in the construction of the achieve this by selecting only the fi nest grades of stainless steel grill is highly rust resistant, however, chlorine in the air from and applying exacting workmanship.
  • Page 34 CLEANING YOUR GRILL ...continued To Remove Brass Burners: WARNING Remove the grill racks and briquette trays. Lift the burner up until the legs exit the frame. DO NOT ALLOW EXCESS GREASE OR LIQUIDS TO AC- CUMULATE IN THE DRIP TRAY AS THIS MAY CREATE A Then pull to the rear of the grill so the burner head comes off FIRE HAZARD.

  • Page 35: Troubleshooting Your Grill

    CLEANING YOUR GRILL ...continued It’s easy to keep your ProSear™ burner operating at peak perfor- When re-installing the ProSear™ burner, be sure to correctly mance. Just run it on “HI” with the hood open for 5 minutes after position the burner. each use to burn away any food particles or drippings.

  • Page 36: Potential Problems

    POTENTIAL PROBLEMS GRILL WON’T LIGHT If the burner will light with a match, then the igniter may not be functioning correctly. Call for service. First, confi rm that the grill is getting electricity by turning on the If the burner will not match light, and you know you are getting lights, then: gas, wait for any gas to dissipate and remove the burner and check it for blockages.
  • Page 37 Bulk LP cylinder lines must be properly regulated. Ensure that you are using a 4/11 appliance regulator supplied by Viking Range, LLC and converted to LP gas. Also ensure that you do not have more than one regulator in line.
  • Page 38 POTENTIAL PROBLEMS ...continued BURNER GOES OUT If, after holding the control knob in for at least 60 seconds, the burner still will not stay lit when releasing the control knob, call • Location for service. First determine if the problem is being caused by location. If (See INDEX: “Obtaining service”...

  • Page 39: Contacting Customer Service

    Clearly describe the problem that you are having. If you are unable to obtain the name of an authorized service agency, or if you continue to have service problems, contact Viking Range, LLC at 1-888-(845-4641), or write to: VIKING RANGE, LLC...

  • Page 40: Viking Range, Llc Outdoor Warranty

    Inspection of the product should be made at time of delivery. Any defects must be reported to the selling dealer within the 90 day period. Viking Range LLC uses the most up to date processes and the best materials available to produce all color fi nishes.

  • Page 41: Wiring Schematics

    WIRING SCHEMATICS 30” ROTISSERIE GRILL INSTALLATION / USE & CARE...

  • Page 42: 42 Rotisserie Grill

    WIRING SCHEMATICS 36” & 42” ROTISSERIE GRILL INSTALLATION / USE & CARE...

  • Page 43: Rotisserie Grill

    WIRING SCHEMATICS 54” ROTISSERIE GRILL INSTALLATION / USE & CARE...
  • Page 44 Viking Range, LLC 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-(845-4641) or visit our web site at vikingrange.com 068958-000D (043021)
