Summary of Contents for Viking Range 5 SERIES
- Page 1 Installation GUIDE 5 SERIES Warming Drawer VWD527 / CVWD527 VWD530 / CVWD530...
-
Page 2: Table Of Contents
Table of Contents Important Safety Instructions __________________________________________________________________________ 2 Dimensions _________________________________________________________________________________________ 3 Specifi cations _______________________________________________________________________________________ 4 Cutout Dimensions___________________________________________________________________________________ 4 Electrical Requirements _______________________________________________________________________________ 5 General Information __________________________________________________________________________________ 5 Installation _________________________________________________________________________________________ 6 Final Preparation ____________________________________________________________________________________ 7 Service & Registration ________________________________________________________________________________ 7 Important Safety Instructions –... -
Page 3: Dimensions
Dimensions 10-1/4” (26.0 cm) 1-1/2” Side View (3.8 cm) 25-1/2” 21-1/4” (64.8 cm) (54.0 cm) VWD527 24-3/4” (62.9 cm) Rear View VWD530 27-3/4” (70.5 cm) 2” (5.1 cm) 9” (22.9 cm) 120 VAC Electrical Connection 2-1/2” (6.4 cm) 1-3/4” WARNING (4.4 cm) ELECTRICAL SHOCK HAZARD This appliance is equipped with a 3-prong power cord... -
Page 4: Specifi Cations
Specifi cations Description VWD527 VWD530 Overall width 26-1/2” (67.3 cm) 29-1/2” (74.9 cm) Overall height 10-1/4” (26.0 cm) Overall depth To end of handle 25-1/2” (64.8 cm) With drawer fully extended 48-1/4” (122.6 cm) Interior width 19-1/8” (48.6 cm 22-1/8” (56.1 cm) Interior height 5-1/2”... -
Page 5: Electrical Requirements
Canadian Electrical Code, CSA C22. General Information • When installing this unit directly below other units, only install with Viking Range, LLC built-in products. •Remove warming drawer carefully from carton. Remove all loose packaging and accessories. • It is the responsibility of the installer to comply with local codes. If no local codes are applicable, wire in accordance with the National Electrical Code, ANSI/NFPA-70 –... -
Page 6: Installation
Installation Pull out warming drawer pan until fully extended Slide fi nger along right and left side until you reach the hand latches (located approximately in the center of the rail). Pull up on on the left side latch and push down on the right side latch at the same time. -
Page 7: Final Preparation
Clearly describe the problem that you are having. If you are unable to obtain the name of an authorized service agency, or if you continue to have service problems, contact Viking Range, LLC at1-888-845-4641, or write to: Viking Range, LLC... - Page 8 Viking Range, LLC 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-845-4641 or visit our website at vikingrange.com in the US or brigade.ca in Canada 062390-000 EN (043017)
