Simplicity Colt ZT2148 Parts Manual page 63

Mower Deck Roller Group
REF NO. PART NO.
1 22845
2 1846892
3 20594
4 25011-10
5 25155
6 1846901
7 25095
8 25846
9 20441
10 25010-10
11 20785
12 46903
13 1846893
14 1846900
15 25139
16 25013-28
17 25156
18 1716353
19 45992
20 25305
21 25096
22 25013-8
23 1841655
24 25128
Footnotes: Ref No. 16-21 apply to the 52" mower only
The above parts group applies to the following Model Nos.:
ZT2148
ZT2148B
ZT2148K
ZT2352
ZT2352B
ZT2352K
TP 400-7034-01-CT-D
QTY.
2 SPRING, Compression
1 MOUNT, Striper-RH
2 COLLAR, Double Split, 3/4
4 CAPSCREW, Hex Hd, 5/16-18 x 1-1/4
4 WASHER, 5/16
1 SHAFT, Striper Guide-RH
4 NUT, Hex, Nylon Lock, 1/4-20
2 BEARING, Flange, 5/8
3 COLLAR, Split, 5/8
4 CAPSCREW, Hex Hd, 1/4-20 x 1-1/4
3 ROLLER
1 SHAFT, Roller Mount
1 MOUNT, Striper-LH
1 SHAFT, Striper Guide-LH
4 NUT, Hex, Serrated Flange, 5/16-18
1 CAPSCREW, Hex Hd, 3/8-16 x 3-1/2
1 WASHER, 3/8
1 WHEEL
1 WHEEL AXLE
1 WASHER, Heavy, 3/8
1 NUT, Hex, Nylon Lock, 3/8-16
1 CAPSCREW, Hex Hd, 3/8-16 x 1
1 ROLLER PIN
1 NUT, Hex, Serrated Flange, 3.8-16
Colt 21 HP Briggs & Stratton Rider w/ 48" Mower
Colt 21 HP Briggs & Stratton Rider w/ 48" Mower
Colt 21 HP Kohler Rider w/ 48" Mower
Colt 23 HP Briggs & Stratton Rider w/ 52" Mower
Colt 23 HP Briggs & Stratton Rider w/ 52" Mower
Colt 23 HP Kohler Rider w/ 52" Mower
DESCRIPTION
57
