Simplicity Colt ZT2148 Parts Manual page 59

Mower Drive Group
REF NO. PART NO.
1A 22667
1B 22148
2A 22622
2B 22721
3 50407-5
4 25318
5 25319
6 25056
7 25158
8 21976
9 47142
10 25017-24
11 25017-36
12 25150
13 45022
14 21541
15 1845106
16 20095
17 45023-009
18 21811
19 25017-28
20 1845200
21 25013-8
22 22788
23 25156
24 25096
25 25128
Footnotes:
The above parts group applies to the following Model Nos.:
ZT2148
ZT2148B
ZT2148K
ZT2352
ZT2352B
ZT2352K
TP 400-7034-01-CT-D
QTY.
1 BELT (48" Deck)
1 BELT (52" Deck)
3 PULLEY, Spindle (48" Deck)
3 PULLEY, Spindle (52" Deck)
3 KEY, 1/4" x 1-1/4"
3 WASHER, Spring
3 NUT, Hex, Nylon Lock, 5/8-18
4 NUT, Hex, Nylon Lock, 1/2-13
3 WASHER, 1/2
3 PULLEY, Idler
2 SPACER, Idler Pulley
2 CAPSCREW, Hex Hd, 1/2-13 x 3
1 CAPSCREW, Hex Hd, 1/2-13 x 4-1/2
2 WASHER, USS, 1/2
1 IDLER ARM PIVOT SHAFT
2 BUSHING, Flange
1 IDLER ARM
1 GREASE FITTING
3 SPACER, Idler
1 EYEBOLT
1 CAPSCREW, Hex Hd, 1/2-13 x 3-1/2
1 SPRING ANCHOR
1 CAPSCREW, Hex Hd, 3/8-16 x 1
1 SPRING, Compression, 2"
1 WASHER, 3/8
1 NUT, Hex, Nylon Lock, 3/8-16
1 NUT, Hex, Serrated Flange, 3/8-16
Colt 21 HP Briggs & Stratton Rider w/ 48" Mower
Colt 21 HP Briggs & Stratton Rider w/ 48" Mower
Colt 21 HP Kohler Rider w/ 48" Mower
Colt 23 HP Briggs & Stratton Rider w/ 52" Mower
Colt 23 HP Briggs & Stratton Rider w/ 52" Mower
Colt 23 HP Kohler Rider w/ 52" Mower
DESCRIPTION
53
