Simplicity Colt ZT2148 Parts Manual page 19

Fuel Tank & Bumper Group
REF NO. PART NO.
1 1846698
* 1847347
2 25299-6
3 45496
4 45494
5 22395
6 25126
7 1846489
* 1847348
8 25011-6
9 1654930
10 1674231
11 22394
12 25155
13 25011-10
14 1846682
15 25128
16 25156
17 25013-8
18 25013-10
19 1846703
20 1846683
21 45495
22 1846490
* 1847349
Footnotes:
The above parts group applies to the following Model Nos.:
ZT2148
ZT2148B
ZT2148K
ZT2352
ZT2352B
ZT2352K
TP 400-7034-01-CT-D
QTY.
1 FUEL TANK TIE BAR (Briggs)
1 FUEL TANK TIE BAR (Kohler)
4 SCREW, Allen Hd, 1/4-20 x 3/4
2 CAP w/ Gauge
1 FUEL TANK-RH, Complete (includes Ref 9 & 10)
4 RUBBER ISOLATOR
4 NUT, Hex, Nylon Lock, 1/4-20
1 MOUNT, Tie Bar-RH (Briggs)
1 MOUNT, Tie Bar-RH (Kohler)
4 CAPSCREW, Hex Hd, 5/16-18 x 3/4
2 RUBBER BUSHING
2 ELBOW FITTING
4 RUBBER BUSHING
4 WASHER, 5/16
4 CAPSCREW, Hex Hd, 5/16-18 x 1-1/4
1 MOUNT, Fuel Tank-RH
6 NUT, Hex, Serrated Flange, 3/8-16
6 WASHER, 3/8
2 CAPSCREW, Hex Hd, 3/8-16 x 1
4 CAPSCREW, Hex Hd, 3/8-16 x 1-1/4
1 BUMPER
1 MOUNT, Fuel Tank-LH
1 FUEL TANK-LH, Complete (includes Ref 9 & 10)
1 MOUNT, Tie Bar-LH (Briggs)
1 MOUNT, Tie Bar-LH (Kohler)
Colt 21 HP Briggs & Stratton Rider w/ 48" Mower
Colt 21 HP Briggs & Stratton Rider w/ 48" Mower
Colt 21 HP Kohler Rider w/ 48" Mower
Colt 23 HP Briggs & Stratton Rider w/ 52" Mower
Colt 23 HP Briggs & Stratton Rider w/ 52" Mower
Colt 23 HP Kohler Rider w/ 52" Mower
DESCRIPTION
13
