Simplicity Colt ZT2148 Parts Manual page 15

Control Cover, Mount & Fan Shield Group
REF NO. PART NO.
1 1719230
* 1719226
* 1719227
2 1846780
3 22030
4 1719392
5 25011-6
6 25155
7 25127
8 1846706
* 1846705
9 25128
10 1846704
11 25013-6
12 1846887
13 1845887
14 22395
15 1845890
16 25156
17 25154
18 25010-6
19 1846890
20 22649
21 22665
22 1846645
23 1846770
24 1846779
Footnotes:
The above parts group applies to the following Model Nos.:
ZT2148
ZT2148B
ZT2148K
ZT2352
ZT2352B
ZT2352K
TP 400-7034-01-CT-D
QTY.
2 HEADLIGHT ASSEMBLY, Complete
2 Headlight
2 Bezel
1 CONTROL COVER-RH
1 VALVE, Fuel Shut Off
1 CUP HOLDER
14 CAPSCREW, Hex Hd, 5/16-18 x 3/4
14 WASHER, 5/16
14 NUT, Hex, Serrated Flange, 5/16-18
1 SUPPORT, Cover-RH
1 SUPPORT, Cover-LH (not shown)
6 NUT, Hex, Serrated Flange, 3/8-16
2 SUPPORT, Control Cover
10 CAPSCREW, Hex Hd, 3/8-16 x 3/4
2 SUPPORT, Control Cover
2 DEBRIS GUARD
4 RUBBER ISOLATOR
2 TANK MOUNT BAR
10 WASHER, 3/8
4 WASHER, 1/4
4 CAPSCREW, Hex Hd, 1/4-20 x 3/4
2 FAN SHIELD MOUNT
4 BODY CLIP, 3/8-16
4 BODY CLIP, 1/4-20
2 FAN SHIELD
1 MOUNT, Oil Filter
1 CONTROL COVER-LH
Colt 21 HP Briggs & Stratton Rider w/ 48" Mower
Colt 21 HP Briggs & Stratton Rider w/ 48" Mower
Colt 21 HP Kohler Rider w/ 48" Mower
Colt 23 HP Briggs & Stratton Rider w/ 52" Mower
Colt 23 HP Briggs & Stratton Rider w/ 52" Mower
Colt 23 HP Kohler Rider w/ 52" Mower
DESCRIPTION
9
