Simplicity Colt ZT2148 Parts Manual page 35

Parking Brake Group - Upper
REF NO. PART NO.
1 1845616
2 1845619
3 1722302
4 25011-8
5 25127
6 21098
7 25013-6
8 25128
9 1847083
10 25010-14
11 25095
12 1847146
13 47119
14 25035
15 25013-16
16 21171
17 25034
18 25096
19 25010-6
20 25154
21 1845621
22 22182
23 25126
24 25058-14
Footnotes:
The above parts group applies to the following Model Nos.:
ZT2148
ZT2148B
ZT2148K
ZT2352
ZT2352B
ZT2352K
TP 400-7034-02-CT-D
QTY.
1 BRAKE HANDLE MOUNT
1 BRAKE HANDLE
1 GRIP
2 CAPSCREW, Hex Hd, 5/16-18 x 1
2 NUT, Hex, Serrated Flange, 5/16-18
2 BEARING, Flange
4 CAPSCREW, Hex Hd, 3/8-16 x 3/4
6 NUT, Hex, Serrated Flange, 3/8-16
1 BRAKE HANDLE SHAFT
2 CAPSCREW, Hex Hd, 1/4-20 x 1-3/4
2 NUT, Hex, Nylon Lock, 1/4-20
1 BRAKE LINKAGE PIVOT
1 BRAKE CONNECTING ROD
1 NUT, Hex, 3/8-24
1 CAPSCREW, Hex Hd, 3/8-16 x 2
1 CLEVIS, 3/8-24
1 NUT, Hex, 3/8-16
1 NUT, Hex, Nylon Lock, 3/8-16
2 CAPSCREW, Hex Hd, 1/4-20 x 3/4
2 WASHER, 1/4
1 SWITCH MOUNT BRACKET
2 SWITCH, NO/NC
2 NUT, Hex, Serrated Flange, 1/4-20
1 CAPSCREW, Hex Hd, TFL, 3/8-16 x 1-3/4
Colt 21 HP Briggs & Stratton Rider w/ 48" Mower
Colt 21 HP Briggs & Stratton Rider w/ 48" Mower
Colt 21 HP Kohler Rider w/ 48" Mower
Colt 23 HP Briggs & Stratton Rider w/ 52" Mower
Colt 23 HP Briggs & Stratton Rider w/ 52" Mower
Colt 23 HP Kohler Rider w/ 52" Mower
DESCRIPTION
29
