Simplicity Colt ZT2148 Parts Manual page 41

Deck Lift Group
REF NO. PART NO.
1 1844999
2 25210
3 1845058
* 44875
4 22044
5 25158
6 10580
7 25096
8 22097
9 1844987
10 44992-009
11 1847043
12 25013-22
13 22045
14 44993
15 25018-24
16 1847105
17 25098
18 25282
19 25516
20 21253
21 20095
22 25013-14
23 25156
24 22366
25 25281
26 25084
27 1845449
* 1845450
28 50878-3
29 25128
30 25325
31 25034
32 25013-10
33 1845451
34 45446
35 25040
36 45447
37 41477
38 22668
39 25159
Footnotes:
The above parts group applies to the following Model Nos.:
ZT2148
ZT2148B
ZT2148K
ZT2352
ZT2352B
ZT2352K
TP 400-7034-01-CT-D
QTY.
1 DECK LIFT LOCK
1 HAIRPIN CLIP
1 DECK LIFT PEDAL
1 SAFETY WALK, Deck Lift Pedal (not shown)
1 PIN, Clevis, 1/2 x 2-1/2
2 WASHER, 1/2
1 COLLAR, Set, 1/2
16 NUT, Hex, Nylon Lock, 3/8-16
1 CAP
1 ARM, Deck Lift Pivot
4 SPACER, Lift Plate
1 DECK HEIGHT PLATE
4 CAPSCREW, Hex Hd, 3/8-16 x 2-3/4
1 PIN, 1/2 x 3
1 LIFT PIVOT BOLT
1 CAPSCREW, Hex Hd, 1/2-20 x 3
2 LINK, Deck Lift
2 NUT, Hex, Nylon Lock, 1/2-20
1 NUT, Hex Jam, Nylon Lock, 5/8-11
2 PIN, Roll, 3/16 x 1-1/2
2 SHIM
4 GREASE FITTING
6 CAPSCREW, Hex Hd, 3/8-16 x 1-3/4
12 WASHER, 3/8
4 PIN, Spring, 3/16 x 1-1/4
4 WASHER, 5/8
2 NUT, Hex Jam, 3/8-16
1 DECK LIFT PIVOT-LH
1 DECK LIFT PIVOT-RH (not shown)
4 CHAIN, 3 Links
4 NUT, Hex, Serrated Flange, 3/8-16
2 U-Bolt
4 NUT, Hex, 3/8-16
2 CAPSCREW, Hex Hd, 3/8-16 x 1-1/4
1 DECK LIFT SHAFT & MOUNT ASSEMBLY
2 SPRING ROD
12 NUT, Hex, 5/8-11
4 SPRING ROD PIVOT
2 SPACER
2 SPRING, Deck Lift
2 WASHER, USS, 5/8
Colt 21 HP Briggs & Stratton Rider w/ 48" Mower
Colt 21 HP Briggs & Stratton Rider w/ 48" Mower
Colt 21 HP Kohler Rider w/ 48" Mower
Colt 23 HP Briggs & Stratton Rider w/ 52" Mower
Colt 23 HP Briggs & Stratton Rider w/ 52" Mower
Colt 23 HP Kohler Rider w/ 52" Mower
DESCRIPTION
35
