Decals - Safety & Operation - Simplicity Colt ZT2148 Parts Manual

Decals - Safety & Operation
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
6
14
8
2
15, 16
3
NOTE: Decals are NOT shown to scale.
The above parts group applies to the following Model Nos.:
ZT2148
ZT2148B
ZT2148K
ZT2352
ZT2352B
ZT2352K
© Copyright 2003 Ferris Industries. All Rights Reserved.
Colt 21 HP Briggs & Stratton Rider w/ 48" Mower
Colt 21 HP Briggs & Stratton Rider w/ 48" Mower
Colt 21 HP Kohler Rider w/ 48" Mower
Colt 23 HP Briggs & Stratton Rider w/ 52" Mower
Colt 23 HP Briggs & Stratton Rider w/ 52" Mower
Colt 23 HP Kohler Rider w/ 52" Mower
1
2
3
4
7
8
5
1
15, 16
4
6
7
8
9
10
11
12
13
14
15
16
48
OPERATION
To Start Engine: To Operate PTO Clutch:
Seat must be occupied, PTO Operator must be in seat.
Switch OFF, Parking Brake ON Pull up to Engage.
and both control handles are Push down to Disengage.
locked in Neutral.
To Stop Engine: When Operator Leaves Seat:
Engage Parking Brake, Throttle at Engine will shut off if PTO is on.
Engine will shut off of Parking Brake
half to full, turn Ignition Switch Off.
is off.
Before Leaving Machine:
Engine will shut off if both control
Turn PTO switch off, shut off engine,
levers are not locked in neutral.
remove key, and set Parking
Brake
GROUND SPEED AND
STEERING LEVERS
Right lever controls speed
and direction of right drive
wheel. Notch is neutral
lock.
Left lever controls speed and
direction of left drive wheel.
Notch is neutral lock.
Steer by slowing the lever in
the direction of the turn.
PARKING BRAKE
LEVER
Pull to set Parking Brake.
Push to release Parking
Brake.
DECK LIFT PEDAL
Push to raise deck.
CUTTING HEIGHT
ADJUSTMENT PIN
DO NOT TOW!
Damage may result to
Hydrostatic Transmission.
POWER DRIVEN PARTS
Key Charge PTO
Auxiliary
Switch Circuit Clutch
20A
20A 20A 20A
46503
52"
48"
TP 400-7034-01-CT-D
47138
WARNING
BEWARE OF
