Fuel Supply Hose Group

NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
LH Fuel Tank
The above parts group applies to the following Model Nos.:
ZT2148
ZT2148B
ZT2148K
ZT2352
ZT2352B
ZT2352K
© Copyright 2003 Ferris Industries. All Rights Reserved.
Connect to Engine
Colt 21 HP Briggs & Stratton Rider w/ 48" Mower
Colt 21 HP Briggs & Stratton Rider w/ 48" Mower
Colt 21 HP Kohler Rider w/ 48" Mower
Colt 23 HP Briggs & Stratton Rider w/ 52" Mower
Colt 23 HP Briggs & Stratton Rider w/ 52" Mower
Colt 23 HP Kohler Rider w/ 52" Mower
6 7
14
3
4
2
1
5
8
RH Fuel Tank
TP 400-7034-01-CT-D
