Simplicity Colt ZT2148 Parts Manual page 27

Pump Drive Group
REF NO. PART NO.
1 46845
2 47075
3 45090
4 22157
5 1846430
6 45135
7 45139
8 25013-32
9 25096
10 25156
11 22621
12 25013-14
13 25128
14A 21826
14B 22847
15 25100
16 25013-18
17 25321
18 25034
19 22314
20 46446
21 22620
22 25013-22
23 22586
24 22156
25 22587
26 25010-8
Footnotes:
The above parts group applies to the following Model Nos.:
ZT2148
ZT2148B
ZT2148K
ZT2352
ZT2352B
ZT2352K
TP 400-7034-01-CT-D
QTY.
1 CRANKSHAFT SPACER
1 CRANKSHAFT PULLEY
1 SPACER, Idler Pivot
2 BUSHING, Brass
1 PUMP DRIVE IDLER ARM
1 SHAFT, Idler Pivot
1 RETAINER, Idler Arm
1 CAPSCREW, Hex Hd, 3/8-16 x 4
3 NUT, Hex, Nylon Lock, 3/8-16
2 WASHER, 3/8
1 PULLEY, Idler (Single Flange)
1 CAPSCREW, Hex Hd, 3/8-16 x 1-3/4
1 NUT, Hex, Serrated Flange, 3/8-16
1 SPRING, Extension
(48" Model - SN: 101-425)
(52: Model - SN: 101-350)
1 SPRING, Extension
(48" Model - SN: 426 & up)
(52: Model - SN: 351 & up)
1 NUT, Hex, Side Lock, 3/8-16
1 CAPSCREW, Hex Hd, 3/8-16 x 2-1/4
1 SCREW HOOK, 3/8-16 x 4-1/4
2 NUT, Hex, 3/8-16
1 BELT, Pump Drive (Set)
1 SPACER, Idler
1 PULLEY, Idler
1 CAPSCREW, Hex Hd, 3/8-16 x 2-3/4
2 PULLEY, Pump Drive
2 KEY, 5mm x 25mm
2 BUSHING, Tapered Hub
4 CAPSCREW, Hex Hd, 1/4-20 x 1
Colt 21 HP Briggs & Stratton Rider w/ 48" Mower
Colt 21 HP Briggs & Stratton Rider w/ 48" Mower
Colt 21 HP Kohler Rider w/ 48" Mower
Colt 23 HP Briggs & Stratton Rider w/ 52" Mower
Colt 23 HP Briggs & Stratton Rider w/ 52" Mower
Colt 23 HP Kohler Rider w/ 52" Mower
DESCRIPTION
21
