1.4.2 TCP/IP

MODBUS TCP, 10Base T output connections are made as shown. Requires 10Base T cable

and Rj45 connector.

Only qualified service personnel should make connections between the System-10 BTU Meter

and the user's external equipment. ONICON assumes no responsibility for damage caused to

the external equipment as a result of an improper installation.
