Onicon System-10 Installation Manual page 25

REGISTER
DESCRIPTION
ADDRESS
40030 Energy Total Mode 2 – MBtu
40031 Energy Total Mode 2 – GBtu
40032 Energy Total Mode 1 – TonHr
40033 Energy Total Mode 1 – kTonHr
40034 Energy Total Mode 2 – TonHr
40035 Energy Total Mode 2 – kTonHr
40036 Energy Total Mode 1 – kWHr
40037 Energy Total Mode 1 – MWHr
40038 Energy Total Mode 1 – GWHr
40039 Energy Total Mode 2 – kWHr
40040 Energy Total Mode 2 – MWHr
40041 Energy Total Mode 2 – GWHr
40042 Volume Total Mode 1 - kGal
40043 Volume Total Mode 1 - MGal
40044 Volume Total Mode 1 – GGal
40045 Volume Total Mode 2 – kGal
40046 Volume Total Mode 2 – MGal
40047 Volume Total Mode 2 – GGal
40048 Volume Total Mode 1 – kLiters
40049 Volume Total Mode 1
40050 Volume Total Mode 1 – GLiters
40051 Volume Total Mode 2 – kLiters
40052 Volume Total Mode 2
40053 Volume Total Mode 2 – GLiters
40054 Volume Total Mode 1 –M³
40055 Volume Total Mode 1 – kM³
40056 Volume Total Mode 2 –M³
40057 Volume Total Mode 2 – kM³
40058 Mass Total – kLbs
40059 Mass Total – MLbs
40060 Mass Total – Kkgs
40061 Mass Total – Mkgs
40062 Auxiliary Input Total (Di3)
40063 Auxiliary Input Total (x1000)
40064 Zero Mode 1 Energy Total
40065 Zero Mode 1 Volume Total
40066 Zero Mode 2 Energy Total
40067 Zero Mode 2 Volume Total
40068 Zero Auxiliary Input Total (Di3)
11451 Belcher Road South, Largo, FL 33773 • USA • Tel +1 (727) 447-6140 • Fax (727) 442-5699 • sales@onicon.com
System-10-MOD Network Interface Installation Guide 08/16 - 0653-13 / 18321
REGISTER
RANGE RANGE
0 – 65535
0 – 65535 0 – 65534
0 – 65535
0 – 65535 0 – 65534
0 – 65535
0 – 65535 0 – 65534
0 – 65535
0 – 65535
0 – 65535 0 – 65534
0 – 65535
0 – 65535
0 – 65535 0 – 65534
0 – 65535
0 – 65535
0 – 65535 0 – 65534
0 – 65535
0 – 65535
0 – 65535 0 – 65534
0 – 65535
MLiters 0 – 65535
–
0 – 65535 0 – 65534
0 – 65535
MLiters 0 – 65535
–
0 – 65535 0 – 65534
0 – 65535
0 – 65535 0 – 65534
0 – 65535
0 – 65535 0 – 65534
0 – 65535
0 – 65535 0 – 65534
0 – 65535
0 – 65535 0 – 65534
0 – 65535
0 – 65535 0 – 65534
0 – 1
0 – 1
0 – 1
0 – 1
0 – 1
DATA OVER
RANGE
0 – 999 Read Only
65535 Read Only
0 – 999 Read Only
65535 Read Only
0 – 999 Read Only
65535 Read Only
0 – 999 Read Only
0 – 999 Read Only
65535 Read Only
0 – 999 Read Only
0 – 999 Read Only
65535 Read Only
0 – 999 Read Only
0 – 999 Read Only
65535 Read Only
0 – 999 Read Only
0 – 999 Read Only
65535 Read Only
0 – 999 Read Only
0 – 999 Read Only
65535 Read Only
0 – 999 Read Only
0 – 999 Read Only
65535 Read Only
0 – 999 Read Only
65535 Read Only
0 – 999 Read Only
65535 Read Only
0 – 999 Read Only
65535 Read Only
0 – 999 Read Only
65535 Read Only
0 – 999 Read Only
65535 Read Only
Not
0 – 1 Read/Write
applicable
Not
0 – 1 Read/Write
applicable
Not
0 – 1 Read/Write
applicable
Not
0 – 1 Read/Write
applicable
Not
0 – 1 Read/Write
applicable
READ/
COMMENT
WRITE
Middle Order
High Order
Low Order
High Order
Low Order
High Order
Low Order
Middle Order
High Order
Low Order
Middle Order
High Order
Low Order
Middle Order
High Order
Low Order
Middle Order
High Order
Low Order
Middle Order
High Order
Low Order
Middle Order
High Order
Low Order
High Order
Low Order
High Order
Mass units are only
available when using
F-2000 Vortex Meter.
Low Order
High Order
Write a value of 1 to
registers to reset totals.
Re-write a value of
zero to registers once
the totals reset.
