ADTEK MWH-10A Operation Manual page 13

MWH-10-A
(Relay Group)
Name Address
0045h
rl-sb
0046h
rl-sd
rl-md 0047h
rl-hy 0048h
rl-rd 0049h
004Ah
rl-fd
004Fh
rYrst
(AO Group)
Name Address
0058h
aOtp
005Ah
ZSclr
005Bh 00.00%~110.00% Analogue Output High Limit
aOlmt
(RS485 Group)
Name Address
adres 005Eh
005Fh
baud
0060h
prity
MODBUS ADDRESS TABLE**Address number are Hexadecima
Range
0000~9999
Start Band of input for relay energized
0000~5999
Start Delay Time of input 1 for relay energized
(0.1second)
0~1 Relay 1 Energized Mode
0: off(no use);
1: lo(Low Energized);
2: hi(High Energized)
3: lo hold(Low Energized Hold)
4: hi hold (High Energized Hold)
0000~5000
Hysteresis of Relay 1
0000~5999
Energized Delay Time of Relay 1
(0.1second)
0000~5999
De-Energized Delay Time of Relay 1
(0.1second)
0~1 Reset for Relay Energized Latch
0: No(
Range
0~5 Analog Output Type
0: 0~5V
3: 0~2.5~5V
6: ±5V
8: 0~10mA
11: 4~12~20mA 12: ± 10 mA 13: ± 20 mA
0~3 The clear of Analogue output zero and
Analogue output span
0: None( none)
1: Analogue output zero ( aOzro)
2: Analogue output span ( aOspn)
3: Both( both)
Range
1~255 RS485 address
0~5 RS485 baud rate
0:1200 1: 2400
4:19200 5:38400
0~3 RS485 parity
0: n-8-1( NstB1) 1: n-8-2( NstB2)
2: odd(
Explain
no) 1: Yes( yes)
Explain
1: 1~5V 2:0~10V
4: 1~3~5V 5:0~5~10V
7: ± 10V
9: 0~20mA 10: 4~20mA
Explain
2:4800 3:9600
odd) 3: even( even)
12
Initial Write/Read Note
0 R/W
0 R/W
2 R/W
0 R/W
0 R/W
0 R/W
0 R/W
Initial Write/Read Note
10 R/W
0 R/W
11000 R/W
Initial Write/Read Note
1 R/W
3 R/W
1 R/W
