GALLERYECLIPSETU - GALLERYECLIPSEDY
6

- 2 - INSTALLATION

2.1 MOUNTING

GALLERYECLIPSETU-DY is designed for applications in exhibition areas, commercial spaces, museums, res-
taurant, churches, and any other installation where size is an important factor. For fixing, stable mounting
clips are required. The mounting place must be of sufficient stability and be able to support a weight of
10 times of the unit's weight.
When carrying out any installation, always comply scrupulously with all the regulations (particularly re-
garding safety) currently in force in the country in which the fixture's being used.
• Install the projector at a suitable location.
• Always additionally secure the projector with the safety rope from falling down. For this purpose, fas-
ten the safety rope at a suitable position so that the maximum fall of the projector will be 20 cm. The
adjust the projector and use the knobs.
NOTE - For the installation of the GALLERYECLIPSEDY make sure that the ridge of the adaptor is in with the
groove of the track. Turn knobs 90° to connect the adaptor to the circuit. Please see the figure 4.
1
2
3
Fig.4
