Altronix ALTV244220 Series CCTV Power Supplies provide 24VAC or 28VAC distributed via four (4) fuse or
PTC protected outputs for powering CCTV cameras, heaters and other video accessories.
Altronix
Model Number
ALTV244220
ALTV244CB220
ALTV244175220
ALTV244175CB220
ALTV244300220
ALTV244300CB220
Agency Listing:
• CE European Conformity.
Input:
• 220VAC (working range 198VAC - 256VAC),
50/60Hz.
Output:
• Four (4) fuse or PTC protected outputs.
• 24VAC or 28VAC supply current.
• Outputs are rated @ 3.5A (fused) or 2.5A (PTC).
• Surge suppression.
1. Mount unit in the desired location. Mark and predrill holes in the wall to line up with the top two keyholes
in the enclosure. Install two upper fasteners and screws in the wall with the screw heads protruding. Place
the enclosure's upper keyholes over the two upper screws; level and secure. Mark the position of the lower
PD4A
two holes. Remove the enclosure. Drill the lower holes and install the fasteners. Place the enclosure's upper
POWER DISTRIBUTING UNIT
INPUT
keyholes over the two upper screws. Install the two lower screws and make sure to tighten all screws
3P 3N 4P 4N
(Enclosure Dimensions, pg. 7, 8). Secure enclosure to earth ground.
2. Slide switch SW1 to the OFF position on models ALTV244220 and ALTV244CB220 (Fig. 1, pg. 4).
Turn main switch on all other models to the OFF position (Figs. 2, 3, pgs. 5, 6).
3. All units are factory set for 24VAC operation.
For 28VAC operation adjust unit prior to mounting and applying power as follows: Change the wire position
so that the black wire [28V] is connected to the terminal marked [P] and the yellow wire [24V] is connected
to the terminal marked [S].
4. Connect unswitched AC circuit (220VAC, 50/60Hz) as follows: Green branch wire (ground) connects to the
terminal marked
[N] of the Inlet Appliance Connector. (Figs. 1-3, pgs. 4-6).
Use 18 AWG or larger for all power connections (Battery, AC output).
- 2 -
Four (4) Output ALTV244 Reference Chart:
Total
Output
Output
Current
Voltage
4A
24VAC
3.5A
28VAC
4A
24VAC
3.5A
28VAC
7.25A
24VAC
6.25A
28VAC
7.25A
24VAC
6.25A
28VAC
12.5A
24VAC
10A
28VAC
10A
24VAC
10A
28VAC
Installation Instructions:
1A
250V
Input
220VAC
, Line connects to the terminal marked [L], and Neutral connects to the terminal marked
50/60Hz,
0.5A
Overview:
4
Specifications:
Features:
• Slow blow main fuse on power distribution board.
• AC power LED.
• Power ON/OFF switch.
• Spare fuses provided.
(all models w/primary and/or secondary fuses).
Enclosure Dimensions:
• ALTV244220 and ALTV244CB220:
8.5" x 7.5" x 3.5" (215.9mm x 190.5mm x 88.9mm).
• ALTV244175220, ALTV244175CB220,
ALTV244300220, and ALTV244300CB220:
8.5" x 7.5" x 3.875" (215.9mm x 191mm x 98.4mm).
–
3.5A
P
–
2.5A
P
–
3.5A
P
–
2.5A
P
–
3.5A
P
–
2.5A
P
5A/
0.5A
250V
10A/
0.8A
250V
15A/
1.8A
32V
ALTV244220 Series
