between the two hash marks.
The TV Wall Mount can be mounted using the Mounting
3.
Hardware included.
Attaching the Vertical Brackets
(Flush Mounting)
To accommodate different TV designs, the TV Wall Mount
comes with five sets of screws of different lengths and
diameters, washers with two hole sizes, and two sizes of
spacers.
Determine the depth and diameter of the mounting holes
1.
located on the back of the TV.
Once you determine the correct depth and diameter of the
2.
hardware needed, Align one of the Vertical Brackets with
the Mounting Holes of the back on the TV.
Note: The Spacers can be used if the included screws are
too long for the TV Mounting Holes.
Place the Rectangular Washers over the Screw Holes on
3.
the Vertical Bracket.
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Proper Use of Bubble Level
