MTS Sensors Temposonics Operation Manual page 7

ACCESSORIES
Position magnet
4
Ø 32.8
Ø 4.3
Ø 23.8
Ø 13.5
7.9
Ring magnet OD33
Part no. 201 542-2
Material: PA ferrite GF20
Weight: ca. 14 g
Operating temperature: −40...+100 °C
Surface pressure: max. 40 N/mm
Fastening torque for M4 screws:
max. 1 Nm
Spanner tool
Part no. DIN 1018A AMF 80-90 mm
HPH rotation adapters
For M18, M30×1,5
Part no. RTA-M18
Cable connectors
~ 60.5
Female, straight, 6 pin
Part no. 370 423
Housing: zinc nickel plated
Termination: solder
Contact insert: silver plated
Cable clamp: PG9
Cable Ø: 6...8 mm
See document "551 444" for further accessories.
Cable glands ATEX
M20 × 1,5
Part no. CG-816679
Type no. ADE1F-4
Material: stainless steel
Cable Ø: 4...8,5 mm
2
For ¾" UNF; 1 1/16
Part no. RTA-¾" UNF-2
Female, straight, 6 pin with
10 m PUR cable
Part no. MTS-A-370423-1000-530052
M20 × 1,5
Part no. CG-816609
Type no. ADE1F-6
Material: stainless steel
Cable Ø: 8.5...16 mm
For ¾" UNF; 1 ¼"
Part no. 253 961
I 7 I
Operation Manual
High Pressure Housing
½" NPT cable gland ATEX/CSA US,
180 °C; Part no. 403 042
Type no. A3LF/16 ½ NPT
Material: nickel plated brass
Cable Ø: 4...8.4 mm
