CC3100BOOST User Guide
J2
J1

3.5 LED and switches

Reference
SW1
SW2
D1
D2
Sense on power
RF Test
Usage
RESET
OOB Demo
GPIO_09
GPIO_08
TI Proprietary Information - Strictly Private
part with 3.3V LDO.
Install this for all boards with the
CC3100Z parts.
Sense on power used for internal debug.
SOP[2:0] = 000 [Functional 4W]
SOP[2:0] = 001 [Functional 2W]
SOP[2:0] = 010 [Load from EEPROM]
SOP[2:0] = 011 [Boot Debug mode]
SOP[2:0] = 100 [UART LOAD]
SOP[2:0] = 101 [TESTMODE 3]
SOP[2:0] = 110 [TESTMODE 2]
SOP[2:0] = 111 [TESTMODE 1]
U.FL connector for conducted testing.
Comments
Reset the CC3100 when mated with the
LP or FTDI board. Useful while updating
the flash contents.
Pull GPIO_13 to Vcc when pressed.
Yellow LED to indicate state of GPIO_09.
LED glows when GPIO_09 goes low.
GREEN LED to indicate state of
