Driver Requirements - Texas Instruments CC3100BOOST User Manual

3
4
Note : On the PC only two of the four ports would be visible on the Device Manager. The
D2XX ports are not listed under the "Ports" tab.
The first COM port in the list usually is used for the flash programming.
Ports available on J2
Port No
1
2

4.3.3 Driver requirements

The FTDI Debug board requires the user to install the associated drivers on a PC. This
package is available as part of the SDK release and would be located at [Install-
Path]\cc3100-sdk\tools\cc31xx_board_drivers\.
The install path is usually C:\ti\cc3100SDK
VCP COM port for flash
programming
VCP RT3
For SL_Prog
Port Type Usage
VCP MAC logg UART Tx for
WLAN Debug
VCP NWP log UART Tx for
debugging
TI Proprietary Information - Strictly Private
CC3100BOOST User Guide
For RF debug using RT3
software
Comments
