system optIons
11.5
PWR FAIL HRS:
11.6
SWGRBYPS TRIPS:
11.7
RST SBYP NO
11.8
TIME CHG NO
HRS FROM GMT:
GMT City/Time Zone
0 London, Monrovia, Lisbon
1 Cape Verde Island, Azores
2 Mid-Atlantic
3 Buenos Aires, Georgetown
4 Atlantic Time (Canada), Caracas
5 Eastern Time (US, Canada) Bogota
6 Central Time (US, Canada) Saskatchewan
7 Mountain Time (US, Canada), Edmonton
8 Pacific Time (US, Canada), Tijuana
9 Alaska
10 Hawaii
11 Midway Island, Samoa
11.9
KYPD INPUT
NONE ECP
Digital Monitoring Products
16

Power Fail Delay

1
This option tracks the duration of a primary power failure. The delay time can be from 1
to 9 hours. When the power is off for the length of the programmed delay time, a power
failure report is sent to the receiver. For example, if the power failure delay is set for
two hours, then the power failure report will be sent between 2-3 hours. Entering a 0
(zero) sends the power failure report within 15 seconds.
Swinger Bypass Trips
2
Enter the number of times (1-6) a zone can go into an alarm or trouble condition within
one hour be fore being auto matically bypassed. Bypassed zones are auto matically reset
when the area they are assigned to is disarmed. All 24-hour zones are reset when any
area of the system is dis a rmed. A programming Stop operation restores a bypassed zone.
Entering 0 (zero) disables this function. Default is 2.
How it works
The communicator hour timer starts at 59 minutes past the hour. If the hour timer
expires before the trip counter is exceeded, the trip counter returns to 0 (zero). If the
trip counter is exceeded before the hour expires, the zone is auto matically bypassed by
the communicator. A Bypass Re p ort is sent to the receiver if Bypass Re p orts is YES.
Reset Swinger Bypass
YES
When YES is selected, an auto m atically bypassed zone is reset if it remains in a normal
condition for one complete hour after being bypassed. A report of the automatic reset is
sent to the receiver if Bypass Reports has been se l ected as YES. Default is NO.
Time Changes
YES
This option allows the communicator to request automatic time changes from the DMP
SCS-1R or SCS-VR Receiver. For the receiver to send time changes, it must be
programmed to send time changes and must be receiving time change updates from the
host automation computer at least every 24 hours. Default is YES.
6
When time zone is programmed YES, enter the number (0-23) that indicates the
Greenwich Mean Time zone (GMT) where the communicator is located. The default is 6.
See table below for GMT values.
Keypad Input
This option allows the iComSL to communicate with Ademco/Honeywell panels over the
Ademco/Honeywell ECP Bus using the zone 4 + and zone 4 - terminals.
This allows the communicator to add and delete User Codes as well as Arm and Disarm
the Ademco/Honeywell panel.
Note: Existing user codes in the Ademco/Honeywell panel must be entered in the
iComSL. Any new user codes entered in the iComSL will also be entered in the Ademco/
Honeywell as well.
Select ECP to enable communication. When NONE is selected, zone 4 functions as a Bell
input. Default is NONE.
See Figure 19: Ademco Vista 20P ECP to iComSL for additional information.
GMT City/Time Zone
12 Fiji, Marshall Island, Wellington
13 New Cadelonia
14 Guam, Sydney
15 Tokyo, Seoul
16 Hong Kong, Singapore
17 Bangkok, Hanoi
18 Dhaka, Almaty
19 Islamabad, Karachi
20 Abu Dhabi, Kazan
21 Moscow, Bagdad
22 Eastern Europe
23 Rome, Paris, Berlin
