Code (NEC) ANSI/NFPA 70 and/or local electrical codes. When the photovoltaic array is exposed to light, it supplies a DC voltage to the Tigo Energy® TS4 units. The TS4 units start in the “ON” state and their output voltage may be as high as the PV module open circuit voltage (V ) when connected to the module.
Plug & play, no configuration required • Transmitter: RSS Transmitter Rapid Shutdown System transmitter for • rapid shutdown activation of TS4-F or TS4-R-F units The external device that provides a • keep-alive signal to the PVRSE device via Power Line Communication.
1.2 TS4 FIRE SAFETY PRODUCTS • NEC 2017 690.12 Rapid shutdown compliant • Module-level deactivation • PLC SunSpec-compliant communication • Plug & play, no configuration required TS4-F Module electronics are contained in the • junction box, installed at the PV module factory.
Method of Operation TS4-F and TS4-R-F units start in the OFF position and measure 0.6V at the output. When power is supplied to the RSS Transmitter, the TS4-F/TS4-R-F units turn ON and allow full PV module voltage.
1.3.2 SYSTEM OVERVIEW: TS4-R-F TS4-R-F Smart Module Add-on Powered by Tigo RSS Transmitter Inverter Note: connect modules to TS4-R inputs before connecting outputs TS4-R mounting is recommended on the upper right as shown, but can be • placed on upper left if needed (due to racking constraints, etc.) TS4-R cable glands must not be facing up.
If parallel string connections are needed, first connect the TS4-F/TS4-R-F to • the PV modules, then connect all TS4-F/TS4-R-F outputs in series, and finally pass one side (+ or -) of the homeruns through the PLC transmitter to turn the system ON.
2.2 TS4-F INSTALLATION Smart modules with an integrated TS4 Junction box are installed and connected in series just like standard PV modules. Connect modules with TS4-F in series before powering on the RSS Transmitter.
2.3 TS4-R-F INSTALLATION Mount the TS4-R-F on Connect the PV the top right corner cables from the of a PV module module to the short leads of the TS4-R-F Connect the long output cables of the TS4-R-F units in series to form strings, as you would with standard PV modules Standard modules can be equipped with TS4-R-F add-on/retrofit...
3.1.1 RSS TRANSMITTER INSTALLATION – SINGLE RSS CORE Install TS4-F before powering on RSS Transmitter Drill holes in enclosure for conduit • (see appendix for placement guide) Mount RSS Transmitter and power supply on DIN rail • Connect DC leads from power supply (1) to transmitter (2) •...
3.1.2 RSS TRANSMITTER WIRING – SINGLE RSS CORE Install TS4-F before powering on RSS Transmitter Pass either positive or negative homerun(s) through RSS Core (CT) • Use the same polarity when passing multiple homeruns through the CT • Connect wires to AC side of power supply •...
3.1.3 RSS TRANSMITTER GROUNDING – SINGLE RSS CORE Install TS4-F before powering on RSS Transmitter Connect AC and DC ground wires to DIN rail • Ground all conduit connections • Turn on AC power to Transmitter power supply to activate •...
3.2.1 RSS TRANSMITTER INSTALLATION – DUAL RSS CORE Install TS4-F before powering on RSS Transmitter Drill holes in enclosure for conduit • (see appendix for placement guide) Mount RSS Transmitter and power supply on DIN rail • Connect DC leads from power supply (1) to transmitter (2) •...
3.2.2 RSS TRANSMITTER WIRING – DUAL RSS CORE Install TS4-F before powering on RSS Transmitter Pass either positive or negative homerun(s) through RSS Core (CT) • Use the same polarity when passing multiple homeruns through the CT • Connect wires to AC side of power supply •...
3.2.3 RSS TRANSMITTER GROUNDING – DUAL RSS CORE Install TS4-F before powering on RSS Transmitter Connect AC and DC ground wires to DIN rail • Ground all conduit connections • Turn on AC power to Transmitter power supply to activate •...
APPENDIX A. Product Specifications B. Testing Rapid Shutdown C. Troubleshooting...
Page 18
4.1.1 TECHNICAL SPECIFICATIONS – TS4-F / TS4-R-F FIRE SAFETY ELECTRICAL RATINGS TS4-F / TS4-R-F INPUT Rated DC Input Power 475W Maximum Input Voltage at Lowest Temperature Max Continuous Input Current (I 12.5A Maximum V @ STC Minimum V OUTPUT Output Power Range...
4.1.3 TECHNICAL SPECIFICATIONS – RSS TRANSMITTER ELECTRICAL RATINGS RSS Transmitter INPUT Input Voltage Input Current Average Supply Power 0.85W Recommended Power Supply Rating and 2A Dimensions (Transmitter only) 90.2mm x 36.3mm x 57.7mm RSS Core 150A per Core Max Current (Single Core: 150A, Dual Core: 300A) Max MPPT String Voltage 1500V...
4.1.4 TECHNICAL SPECIFICATIONS – RSS TRANSMITTER OUTDOOR KIT ELECTRICAL RATINGS RSS Transmitter Outdoor Kit INPUT Input Voltage 12VDC Input Current Average Supply Power 0.85W Recommended Power Supply Rating 12VDC and 2A Dimensions (Transmitter only) 90.2mm x 36.3mm x 57.7mm RSS Core 100A per Core Max Current (Single Core: 100A, Dual Core: 200A)
4.2 TESTING RAPID SHUTDOWN TS4-F (or TS4-R-F) and an RSS Transmitter are a solution to meet NEC 2014 & 2017 690.12 Rapid Shutdown requirements. TS4-F and TS4-R-F units automatically enter rapid shutdown mode when the RSS Transmitter is switched off and resume energy production when power is restored to the RSS Transmitter.
V If output is 0V contact Tigo support • Check that the system conforms to the design rules for TS4-F: Up to 10 strings per RSS Core (CT) • Up to 30 modules per string • String length up to 1000ft (total cable length from + to - ) •...
