- Page 1 Installation Manual TS4-F, TS4-A-F, TS4-A-2F and RSS Transmitter...
- Page 2 National Electric Code (NEC) ANSI/NFPA 70 and/or local electrical codes. When the photovoltaic array is exposed to light, it supplies a DC voltage to the Tigo TS4 units. The TS4 units start in the “ON” state and their output voltage may be as high as the PV module open circuit voltage (VOC) when connected to the module.
-
Page 3: Table Of Contents
TABLE OF CONTENTS TS4-F Rapid Shutdown System TS4 Fire Safety Products System Overview: TS4-F System Overview: TS4-A-F System Overview: TS4-A-2F Installation Notes TS4-F Installation TS4-A-F Installation TS4-A-2F Installation RSS Transmitter Commercial Installation Technical Specifications – TS4-F Mechanical Specifications – TS4-F Technical Specifications –... -
Page 4: Ts4-F Rapid Shutdown System
• Rapid Shutdown System Transmitter for rapid shutdown activation of TS4-F or TS4-A-F units • The external device that provides a keep- alive signal to the TS4-F via Power Line Communication • Integrated in CPS 25/50/60kW Inverter Tigo RSD wire-boxes... -
Page 5: Ts4 Fire Safety Products
TS4 FIRE SAFETY PRODUCTS Module-Integrated: TS4-F • Module electronics are contained in the junction box, installed at the PV module factory. • Connected in series like regular modules • No additional wiring connections to make Add-on: TS4-A-F • Bracket clips to module frame without tools •... -
Page 6: System Overview: Ts4-F
The TS4-F requires a Tigo RSS Transmitter or inverter with built-in transmitter for operation. The Tigo RSS Transmitter is installed in line with a solar PV inverter, as shown, and can be installed inside the inverter or external to it. -
Page 7: System Overview: Ts4-A-F
Tigo RSD wire-boxes) 3. Inverter Note: connect modules to TS4-A inputs before connecting outputs The TS4-A-F requires a Tigo RSS Transmitter or inverter with built-in transmitter for operation. • TS4-A-F mounting is recommended on the upper right as shown, but can be placed elsewhere on the frame or bolted to the racking if needed. -
Page 8: System Overview: Ts4-A-2F
Tigo RSD wire-boxes) 3. Inverter Note: connect modules to TS4-A inputs before connecting outputs The TS4-A-2F requires a Tigo RSS Transmitter or inverter with built-in transmitter for operation. • TS4-A-F mounting is recommended on the upper right as shown, but can be placed elsewhere on the frame or bolted to the racking if needed. -
Page 9: Installation Notes
INSTALLATION NOTES • TS4-F and TS4-A-F are shipped in the OFF position and will measure 0.6V at the output when the keep-alive signal is not present. • Failing to follow the sequence of installation steps may result in TS4 damage not covered under warranty. -
Page 10: Ts4-F Installation
TS4-F INSTALLATION Smart modules with an integrated TS4 Junction box are installed and connected in series just like standard PV modules. Connect modules with TS4-F in series before powering on the RSS Transmitter. TS4-F TS4-F 4 - 123A 4 - 123A... -
Page 11: Ts4-A-F Installation
To disconnect TS4-A-F from a module, disconnect the TS4-A-F outputs from the string before disconnecting the TS4-A-F inputs from the module junction box. Tigo Rapid Shutdown Tigo Rapid Shutdown NEC 690.12-2017 and C22.1-2015 Rule 64.218 NEC 690.12-2017 and C22.1-2015 Rule 64.218... -
Page 12: Ts4-A-2F Installation
If connecting 2F to a single PV module: • Connect PV module to Input 1 • Connect Input 2 cables together Tigo Rapid Shutdown NEC 690.12-2017 and C22.1-2015 Rule 64.218 TS4-A-2F DO NOT DISCONNECT UNDER LOAD 4 - 123A... -
Page 13: Rss Transmitter Commercial Installation
3 RSS Core (CT) Transmitter power supply must be on same AC branch circuit as inverter to meet rapid shutdown requirements. Note: Install TS4-F before powering on RSS Transmitter Place rapid shutdown system label no more than 1m (3ft) from RSS Transmitter... - Page 14 Rapid Shutdown System Transmitter G L2 L1 Note: Install TS4-F before powering on RSS Transmitter · Turn on AC power to Transmitter power supply to activate keep-alive signal Max string length: 30 modules Max current per RSS Core: 150A Max cable length from inverter (+) to inverter (-): 1000ft (300m)
- Page 15 Appendix TS4-F, TS4-A-F, RSS Transmitter...
-
Page 16: Technical Specifications
TECHNICAL SPECIFICATIONS – TS4-F (Module-Integrated) TS4-F Electrical Ratings Fire Safety Input Rated DC Input Power 475W Input Voltage 16 - 90V Max Continuous Input Current (I 12.5A Output Output Power Range 0 - 475W Output Voltage Range 0 – V... -
Page 17: Mechanical Specifications - Ts4-F
MECHANICAL SPECIFICATIONS – TS4-F TS4-F Specifications Fire Safety Mechanical Operating Temperature Range: -40°C to +70°C (-40°F to +158°F), RH < 85% Storage Temperature Range: -40°C to +70°C (-40°F to +158°F), RH < 60% Cooling Method Natural Convection Dimensions (with cover) 178.5mm x 134mm x 25.5mm... -
Page 18: Technical Specifications - Ts4-A-F
TECHNICAL SPECIFICATIONS – TS4-A-F Specifications TS4-A-F Fire Safety Environmental Operating Temperature Range -40°C to +85°C (-40°F to +185°F) Outdoor Rating IP68, NEMA 3R Mechanical Dimensions 138.4mm x 139.7mm x 22.9mm Weight 490g Electrical Input Voltage 16 - 90V Maximum Continuous Input Current (I 12.5A Maximum Power 500W... -
Page 19: Technical Specifications - Ts4-A-2F
TECHNICAL SPECIFICATIONS – TS4-A-2F Specifications TS4-A-2F Fire Safety Environmental Operating Temperature Range -40°C to +70°C (-40°F to +158°F) Outdoor Rating IP68, NEMA 3R Mechanical Dimensions 138.4mm x 139.7mm x 22.9mm Weight 590g Electrical Voltage Range (per input) 16 - 90V Maximum Current (per input) Maximum Power (total) 1000W... -
Page 20: Technical Specifications - Rss Transmitter
TECHNICAL SPECIFICATIONS – RSS TRANSMITTER Electrical Ratings RSS Transmitter Input Input Voltage Input Current Average Supply Power 0.85W Dimensions(Transmitter only) 90.2mm x 36.3mm x 57.7mm RSS Core 150A per Core Maximum Current (Single Core: 150A, Dual Core: 300A) Maximum MPPT String Voltage 1500V Internal Opening for Wires ~25mm... -
Page 21: Testing Rapid Shutdown
TESTING RAPID SHUTDOWN TS4-F (or TS4-A-F, TS4-A-2F) and an RSS Transmitter are a solution to meet NEC 2014 & 2017 690.12 Rapid Shutdown requirements. TS4-F, TS4-A-F, and TS4-A-2F units automatically enter rapid shutdown mode when the RSS Transmitter is switched off and resume energy production when power is restored to the RSS Transmitter. -
Page 22: Installation Complete
For more details on designing and installing solutions powered by Tigo, please visit: Tigo Academy Resource Center Or contact us at: training@tigoenergy.com Tigo Energy, Inc. 655 Campbell Technology Pkwy Suite 150, Campbell, California 95008 USA www.tigoenergy.com P: +1.408.402.0802 F:+1.408.358.6279 | sales@tigoenergy.com...
