- Page 1 Installation Manual TS4-F, TS4-R-F, TS4-A-F, RSS Transmitter...
-
Page 2: Important Safety Instructions
National Electric Code (NEC) ANSI/NFPA 70 and/or local electrical codes. When the photovoltaic array is exposed to light, it supplies a DC voltage to the Tigo TS4 units. The TS4 units start in the “ON” state and their output voltage may be as high as the PV module open circuit voltage (VOC) when connected to the module. -
Page 3: Table Of Contents
TABLE OF CONTENTS TS4-F Rapid Shutdown System Technical Specifications – RSS Transmitter Commercial Kit TS4 Fire Safety Products Technical Specifications – RSS Transmitter Outdoor Kit System Overview: TS4-F Testing Rapid Shutdown System Overview: TS4-R-F Conduit Drilling Guide System Overview: TS4-A-F... -
Page 4: Ts4-F Rapid Shutdown System
• Plug & play, no configuration required Transmitter: RSS Transmitter • Rapid Shutdown System Transmitter for rapid shutdown activation of TS4-F, TS4-R-F, or TS4-A-F units • The external device that provides a keep- alive signal to the TS4-F via Power Line Communication... -
Page 5: Ts4 Fire Safety Products
TS4 FIRE SAFETY PRODUCTS Module-Integrated: TS4-F • Module electronics are contained in the junction box, installed at the PV module factory. • Connected in series like regular modules • No additional wiring connections to make Add-on/Retrofit: TS4-R-F, TS4-A-F • Bracket clips to module frame without tools •... -
Page 6: System Overview: Ts4-F
The TS4-F requires a Tigo RSS Transmitter or inverter with built-in transmitter for operation. The Tigo RSS Transmitter is installed in line with a solar PV inverter, as shown, and can be installed inside the inverter or external to it. -
Page 7: System Overview: Ts4-R-F
4 - 123A Transmitter Note: connect modules to TS4-R inputs before connecting outputs The TS4-R-F requires a Tigo RSS Transmitter or inverter with built-in transmitter for operation. • TS4-R-F mounting is recommended on the upper right as shown, but can be placed elsewhere on the frame or bolted to the racking if needed. -
Page 8: System Overview: Ts4-A-F
UNDER LOAD Transmitter Note: connect modules to TS4-A inputs before connecting outputs The TS4-A-F requires a Tigo RSS Transmitter or inverter with built-in transmitter for operation. • TS4-A-F mounting is recommended on the upper right as shown, but can be placed elsewhere on the frame or bolted to the racking if needed. -
Page 9: Installation Notes
INSTALLATION NOTES • TS4-F, TS4-R-F, and TS4-A-F are shipped in the OFF position and will measure 0.6V at the output when the keep-alive signal is not present. • Failing to follow the sequence of installation steps may result in TS4 damage not covered under warranty. -
Page 10: Ts4-F Installation
TS4-F INSTALLATION Smart modules with an integrated TS4 Junction box are installed and connected in series just like standard PV modules. Connect modules with TS4-F in series before powering on the RSS Transmitter. TS4-F TS4-F 4 - 123A 4 - 123A... -
Page 11: Ts4-R-F Installation
TS4-R-F INSTALLATION Standard modules can be equipped with TS4-R-F add-on/retrofit units as shown below. Always connect modules to TS4-R inputs before connecting outputs. Each TS4-R-F must have a PV module connected to its input before connecting the outputs of TS4-R-F units in series. To disconnect TS4-R-F from a module, disconnect the TS4-R-F outputs from the string before disconnecting the TS4-R-F inputs from the module junction box. -
Page 12: Ts4-A-F Installation
To disconnect TS4-A-F from a module, disconnect the TS4-A-F outputs from the string before disconnecting the TS4-A-F inputs from the module junction box. Tigo Rapid Shutdown Tigo Rapid Shutdown NEC 690.12-2017 and C22.1-2015 Rule 64.218 NEC 690.12-2017 and C22.1-2015 Rule 64.218... -
Page 13: Rss Transmitter Installation - Single Rss Core
Suggested locations for conduit Transmitter power supply must be on same AC branch circuit as inverter to meet rapid shutdown requirements. Note: Install TS4-F before powering on RSS Transmitter · Drill holes in enclosure for conduit (see drilling guide for placement) ·... -
Page 14: Rss Transmitter Wiring - Single Rss Core
Homerun Only (+) or (-) through RSS Core Note: Install TS4-F before powering on RSS Transmitter · Pass either positive or negative homerun through RSS Core · Connect wires to AC side of power supply Max number of strings per RSS Core: 10... -
Page 15: Rss Transmitter Grounding - Single Rss Core
DC Ground Transmitter AC Ground Conduit Ground Note: Install TS4-F before powering on RSS Transmitter · Connect AC and DC ground wires to DIN rail · Ground all conduit connections · Turn on AC power to Transmitter power supply to activate... -
Page 16: Rss Transmitter Installation - Dual Rss Core
Suggested locations for conduit Transmitter power supply must be on same AC branch circuit as inverter to meet rapid shutdown requirements. Note: Install TS4-F before powering on RSS Transmitter · Drill holes in enclosure for conduit (see drilling guide for placement) ·... -
Page 17: Rss Transmitter Wiring - Dual Rss Core
Only (+) or (-) through RSS Core Homerun Note: Install TS4-F before powering on RSS Transmitter · Pass either positive or negative homerun through RSS Cores · Connect wires to AC side of power supply Max number of strings per RSS Core: 10... -
Page 18: Rss Transmitter Grounding - Dual Rss Core
DC Ground Transmitter AC Ground Conduit Ground Note: Install TS4-F before powering on RSS Transmitter · Connect AC and DC ground wires to DIN rail · Ground all conduit connections · Turn on AC power to Transmitter power supply to activate... -
Page 19: Rss Transmitter Commercial Installation
RSS Core (CT) Transmitter power supply must be on same AC branch circuit as inverter to meet rapid shutdown requirements. Note: Install TS4-F before powering on RSS Transmitter · Mount RSS Transmitter and power supply on DIN rail · Connect DC leads from power supply (1) to transmitter (2) ·... -
Page 20: Rss Transmitter Commercial Wiring
Homerun Only (+) or (-) through RSS Core Note: Install TS4-F before powering on RSS Transmitter · Pass either positive or negative homerun through RSS Cores · Connect wires to AC side of power supply · Turn on AC power to Transmitter power supply to activate... - Page 21 Appendix TS4-F, TS4-R-F, TS4-A-F, RSS Transmitter...
-
Page 22: Technical Specifications - Ts4-F / Ts4-R-F
TECHNICAL SPECIFICATIONS – TS4-F / TS4-R-F Electrical Ratings TS4-F / TS4-R-F Fire Safety Input Rated DC Input Power 475W Input Voltage 16 - 90V Max Continuous Input Current (I 12.5A Output Output Power Range 0 - 475W Output Voltage Range 0 –... -
Page 23: Mechanical Specifications - Ts4-F / Ts4-R-F
MECHANICAL SPECIFICATIONS – TS4-F / TS4-R-F Specifications TS4-F / TS4-R-F Fire Safety Mechanical Operating Temperature Range: -40°C to +70°C (-40°F to +158°F), RH < 85% Storage Temperature Range: -40°C to +70°C (-40°F to +158°F), RH < 60% Cooling Method Natural Convection Dimensions (with cover) 178.5mm x 134mm x 25.5mm... -
Page 24: Technical Specifications - Ts4-A-F
TECHNICAL SPECIFICATIONS – TS4-A-F Specifications TS4-A-F Fire Safety Environmental Operating Temperature Range -40°C to +85°C (-40°F to +185°F) Outdoor Rating IP68, NEMA 3R Mechanical Dimensions 138.4mm x 139.7mm x 22.9mm Weight 490g Electrical Input Voltage 16 - 90V Maximum Continuous Input Current (I 12.5A Maximum Power 500W... -
Page 25: Technical Specifications - Rss Transmitter
TECHNICAL SPECIFICATIONS – RSS TRANSMITTER Electrical Ratings RSS Transmitter Input Input Voltage Input Current Average Supply Power 0.85W Dimensions(Transmitter only) 90.2mm x 36.3mm x 57.7mm RSS Core 150A per Core Maximum Current (Single Core: 150A, Dual Core: 300A) Maximum MPPT String Voltage 1500V Internal Opening for Wires ~25mm... -
Page 26: Technical Specifications - Rss Transmitter Commercial Kit
TECHNICAL SPECIFICATIONS – RSS TRANSMITTER COMMERCIAL KIT Electrical Ratings RSS Transmitter Input Input Voltage Input Current Average Supply Power 0.85W Included Power Supply Rating 480/277V input, 12V output Dimensions(Transmitter only) 90.2mm x 36.3mm x 57.7mm RSS Core Maximum Current 150A per Core (includes 2 Cores for 300A) Maximum MPPT String Voltage 1500V Internal Opening for Wires... -
Page 27: Technical Specifications - Rss Transmitter Outdoor Kit
TECHNICAL SPECIFICATIONS – RSS TRANSMITTER OUTDOOR KIT Electrical Ratings RSS Transmitter Input Input Voltage Input Current Average Supply Power 0.85W Dimensions(Transmitter only) 90.2mm x 36.3mm x 57.7mm RSS Core 100A per Core Maximum Current (Single Core: 100A, Dual Core: 200A) Maximum MPPT String Voltage 1500V Internal Opening for Wires... -
Page 28: Testing Rapid Shutdown
TESTING RAPID SHUTDOWN TS4-F (or TS4-R-F / TS4-A-F) and an RSS Transmitter are a solution to meet NEC 2014 & 2017 690.12 Rapid Shutdown requirements. TS4-F, TS4-R-F, and TS4-A-F units automatically enter rapid shutdown mode when the RSS Transmitter is switched off and resume energy production when power is restored to the RSS Transmitter. -
Page 29: Conduit Drilling Guide
CONDUIT DRILLING GUIDE Enclosure Drilling Guide for .75" Conduit Single Core Dual Core 41.6 41.6 41.6 41.6 47.1 47.1 47.1 47.1 2X Ø 28 Ø 28 3X Ø 28 2X Ø 28 Enclosure Drilling Guide for 1" Conduit Single Core Dual Core 41.6 41.6... -
Page 30: Installation Complete
INSTALLATION COMPLETE Problems? TS4-F Troubleshooting Guide For more details on designing and installing solutions powered by Tigo, please visit: Tigo Academy Resource Center Or contact us at: training@tigoenergy.com... -
