Siemens DataNET Hub (DNH) User Manual page 82

Command Descriptions,
"display links"
Command
Example: local> display
links
Port status for 161.218.54.235, A
Port:
1
2
3
4
5
6
7 DIAG Copper
8
9
Ethernet
Cross
local>
Example: local> display
links 3
"download"
Command
74 • • • • Command Summary
Continued
This command displays the hub-half's link state table. The link state table
indicates, for each link, whether or not the link is currently "connected,"
"unconnected," or undergoing link validation ("validation"). For DataNET
links (including the cross-link), the table also gives the device to which
the link connects. DataNET devices are identified by their device IDs.
In this example, port 7 is running in diagnostic mode (see "test" com-
mand) and port 1 is validating its link to device 8.8.8.8. Port 5 has been
taken offline, either with the "port stop" command, or because the hub
detected a loop in the DataNET topology.
Medium: Status:
Copper Validation
Copper Unconnected
Copper Unconnected
Copper Unconnected
Copper Offline
Copper Unconnected
Unconnected
Copper Unconnected
Copper Unconnected
Up
Connected
If a hub port is connected to an Advance Network Gateway with Data-
NET the display link command will also provide enhanced configuration
information when the link number is specified
Use this command to load new firmware into the hub-half via the RS-232
Configuration port. The procedure for firmware download is:
1. Make sure you have a "hub_rom.mot" file available for download.
2. Log into the target Hub through the Configuration port, using Hyper-
Term.
3. Type "download" at the hub's prompt (">"). The hub will then prompt
to begin transmitting the download file.
4. Transmit the download file. Use the HyperTerm "Transfer --> Send
Text File..." command. Find the "hub_rom.hex" file using the browser
window. You may have to select "Show all files" in the "Files of type"
window to see the "hub_rom.mot" file.
"A" connected to:
161.218.54.232, 1A
161.218.054.251, 1A
"B" connected to:
161.28.54.233, 1B
161.218.054.252, 1B
2000585-001
