Site Wiring Requirements,
DataNET Channels
Table 2-1.
Recommended DataNET
Cable
20 • • • • Installation
Continued
The DataNET channel connections can be either copper wire or fiber
optic cable. The wiring method and cable type for DataNET is dependent
upon the site requirements. For cable requirements see Table 2-1.
The following Table should be used when evaluating or selecting cable
for an existing or new DataNET installation.
Cable Type
Fiber Optic
MM 62.5/125; 2 Fiber
Conductors
2- Conductor Copper
Wire
4-Conductor Copper
Wire
Ethernet Cat 5 Un-
shielded Twisted pair
(UTP)
Vendors & P/N
SAA P/N 1270002-002
Industry Available from
Multiple Vendors
SAA P/N 1686002-001
Belden P/N 9182
for
Belden Armored Cable
order
SAAI P/N 1680000-002
SAA P/N 1681000-003
Belden P/N SSD1743
SAA P/N 1681003-006
Industry Available from
Multiple Vendors
Installation Notes
New Installation as an
alternative to copper
cable
Max distance from Ana-
lyzer to Hub or between
Hubs 1520 meters
(5000 ft)
Recommended for Sin-
gle Channel
Max distance from Ana-
lyzer to Hub or between
Hubs 1520 meters
(5000 ft)
Recommended for Dual
Channel
Max distance from Ana-
lyzer to Hub or between
Hubs 1520 meters
(5000 ft)
Recommended for
short distances or
within shelters.
Max distance from ana-
lyzer to hub or between
hubs 600 meters (2000
ft)
