Siemens DataNET Hub (DNH) User Manual page 79

Command Descriptions,
"config address ip"
command
"config device id"
Command
"config display"
Command
"config netmask"
Command
2000585-001
Continued
This command configures the hub-half IP address. Each individual hub
board ("hub-half") in the system must have a unique IP address. Your
network administrator can help you choose appropriate addresses for
your DataNET hubs. IP addresses are entered in "dotted-decimal" nota-
tion. For example:
config address ip 192.10.6.123
The IP address is automatically stored in the hub-half's non-volatile
memory when you enter this command. You can display the current IP
address with the config display command.
Each pair of hub boards shares a common "device ID." This ID must be
configured into each board's non-volatile memory at installation time with
the config device id command. Device Ids have the same form as IP
addresses (i.e., four dotted-decimal components, in the range 0 through
255). Any value may be chosen for device IDs. The only requirements
are that each pair of hub boards that make up a complete hub, share the
same device ID and that device IDs are not duplicated between any hubs
in a single DataNET.
One convenient convention for assigning device IDs is to use the IP ad-
dress of the "A" half of each pair as the device ID.
This command displays the settings for the hub's non-volatile configura-
tion parameters.
This command sets the IP subnet mask for a hub-half. Your network ad-
ministrator can help you choose an appropriate subnet mask for your
DataNET hubs (subnet masks are not always required). Subnet masks
are entered in "dotted-decimal" notation. For example:
config netmask 255.255.192.0
The subnet mask is automatically stored in the hub-half's non-volatile
memory when you enter this command. You can display the current sub-
net mask with the config display command.
Command Summary • • • • 71
