DataNET Hub Specifications,
Communication
Comparisons
Feature
Speed
Redundant
Number of Units in
Maxum System
DataNET Cable
Cable Type
Fiber Optic
MM 62.5/125; 2 Fiber Conductors
2- Conductor Copper Wire
4-Conductor Copper Wire
Ethernet Cat 5 Unshielded Twisted
pair (UTP)
2000585-001
Continued
The Table below compares key communication features between using
Advance Data Hiway, Ethernet, or DataNET.
Advance Data Hiway
14.2 KB/Sec
Yes
248
The following Table should be used when evaluating or selecting cable
for an existing or new DataNET installation.
Vendors & P/N
SAA P/N 1270002-002
Industry Available from Mul-
tiple Vendors
SAA P/N 1686002-001
Belden Armored Cable or-
SAA P/N 1681000-003
Belden P/N SSD1743
SAA P/N 1681003-006
Industry Available from Mul-
tiple Vendors
Ethernet
10 M baud
No
1200
Belden P/N 9182
for
der
SAA P/N 1680000-002
DataNET
2. 048 M baud
Yes
1200
Installation Notes
New Installation as an al-
ternative to copper cable
Max distance from Analyzer
to Hub or between Hubs
1520 meters (5000 ft)
Recommended for Single
Channel
Max distance from Analyzer
to Hub or between Hubs
1520 meters (5000 ft)
Recommended for Dual
Channel
Max distance from Analyzer
to Hub or between Hubs
1520 meters (5000 ft)
Recommended for short
distances or within shelters.
Max distance from analyzer
to hub or between hubs 600
meters (2000 ft)
