Ethernet Connections,
10BASE-T Cable
Requirements
46 • • • • Installation
Continued
1. The 10BASET data cable requires a minimum of two twisted pairs
(transmit pair and a receive pair). The type wire used should conform
to the AT&T D-inside wire (DWI & PDS), or IBM Type 3, or Category
3 or 5 data grade or equivalent specifications.
2. The maximum length of a 10BASET data cable can not exceed 328
feet (100 meters). Typically to increase the distance each DNH will
connect to a hub or other type of repeater/medium converter.
3. The cable should be terminated at both ends with RJ-45 STP male
connectors. The table below shows the RJ-45 wiring connections for
the DNH end of the cable.
Pin No. MDI Function
1
2
3
4
5
6
7
8
TX+
TX-
RX+
NC
NC
RX-
NC
NC
2000585-001
