Comtech EF Data MBT-4000B User's Installation And Operation Manual page 68

MBT-4000B Multi-band Transceiver System
Serial-based Remote Product Management
Command
Parameter (Instruction Code
Type and qualifier) BUC/BDC
Retrieve N/A All
Configuration
Status
Redundancy RED=x MBT
State
Arguments for
Valid on
Command or
MBT or (Note that all arguments are ASCII numeric codes – i.e., ASCII codes
Response to
Query
65 bytes (MBT), Query only.
98 bytes (BDC), Returns the configuration status of the unit
76 bytes (BUC),
alphanumeric Example for MBT-4000B base:
<0001/RCS?{cr}
>0001/RCS={cr}
BF1=X {cr}
BF2=X {cr}
BT1=DN{cr}
BT2=UP{cr}
RED=0{cr}
RAM=00{cr}
MBT=N, A, or B
EXT=0{cr}{lf}
Example for BUC/BDC:
<0001A1/RCS?{cr}
>0001A1/RCS={cr}
FLO=06300{cr}
ATT=01.00{cr}
MUT=1{cr}
SLP=0.3{cr}
LCS=0{cr}
LCW=99{cr}
LFL=1{cr}
REF=XXXX{cr} (reserved for future use)
XRE=X{cr} (reserved for future use)
AFR=0{cr}{lf}
Note: For BUC – LCS, LCW, & LFL will not be shown.
1 byte Command or Query.
Controls redundancy state in the form x, where:
x=0 (Off),
1 (Enables redundancy using single base unit), or
2 (Enables redundancy using dual base units)
Example: RED=1
Description of Arguments
between 48 and 57)
6–18
MN/MBT4000B.IOM
Query
Response to Command (Instruction
(Target to Controller) Code and
qualifier)
N/A RCS?
RED= RED?
RED?
RED*
Revision 1
Response to
Query
(Target to
Controller)
RCS=x....x
(see Description of
Arguments for
details)
RED=x
(same format as
command
arguments)
