MBT-4000B Multi-band Transceiver System
Updating Firmware
5.4

Performing the FTP Upload Procedure

To proceed with the firmware update procedure, assumptions are made that:
•
•
Step Task
1
Double-click FLSHCSAT.EXE
(filename or icon) to execute the
FTP upload utility.
2 From the FLSHCSAT window,
select the pertinent serial port
used for communication between
the User PC and the MBT-4000B
(Item 'A' in this example shows
that COM1 has been selected)
3
Do not select a baud rate (Item
'B') other than the default selection
of 38400, unless otherwise
instructed by Comtech EF Data
Technical Support.
4
Click [Software Upload] (Item 'C')
5
You are prompted to select a file
to upload. Click [Choose File].
Then, from the dialogue window
that opens, use the drop-down list
to select the drive (if needed), and
then navigate to the temporary
folder created earlier. Finally,
double-click on the firmware file
from the window to the left.
The MBT-4000B is connected to a user-supplied, Windows-based PC:
o The PC serial port is connected to the MBT4000B's 'J2 |COMM' port using
the appropriate adaptive cabling.
o The PC is running a terminal emulation program (for operation of the
MBT-4000B Serial Interface).
The latest firmware files have been downloaded or otherwise received from
Comtech EF Data and are available on the User PC in an accessible temporary
folder.
5–9
Revision 1
MN/MBT4000B.IOM
