MBT-4000B Multi-Band Transceiver System
System Operating Parameters
4.5

Block Up Converter Module (BUC-4000) Operating Parameters

The BUC-4000 translates an L-Band output carrier to the desired output frequency (C-, X-, Ku,- or
Ka-Band) with an output level capable of driving a High-Power Amplifier (HPA).

Table 4-1. BUC-4000 C-, X-, Ku-, and Ka-Band Operating Parameters

Band
C-Band
X-Band
Ku-Band-W
Ka-Band
Notes:
1. No spectral inversion.
2. 10dB gain adjustment.
Frequency LO Frequency
5850 to 6650 MHz 4900 MHz
7900 to 8400 MHz 6950 MHz
13.75 to 14.50 GHz 12.800 GHz
30.00 to 31.00 GHz
4–3
Revision 1
MN/MBT4000B.IOM
Inverting
No
No
No
