Summary of Specifications

1.4.1 Environmental & Physical
Temperature
ODU: BUC-4000
Operational Humidity
Operational Altitude
Prime Power
ODU: MBT-4000B
Dimensions (excluding connectors)
1.4.2

BUC-4000 Block Up Converter ODU

Input Frequency Range
Output Frequency
(by model)
Input/Output Impedance
Input Return Loss
Output Return Loss
Input Connector
Output Connector
Gain
User Attenuation Range
Output Power, P1dB
Third Order Intercept
Spurious
External Reference
Operating
Non-operating
BUC-4000C
BUC-4000X
BUC-4000Ku
BUC-4000Ka
Carrier Related
Non-Carrier Related
-40º to 122ºF (-40º to 50ºC)
-58º to 167ºF (-50º to 75ºC)
5 to 95% non-condensing
10,000 ft above sea level
90 to 260 VAC, 47 to 63 Hz
See Figure 1-4
950 to 2000 MHz, 125 kHz steps
1 kHz (optional)
5860 to 6650 MHz
7900 to 8400 MHz
13.75 to 14.50 GHz
30.00 to 31.00 GHz
27.50 to 28.50 GHz (optional)
28.50 to 29.50 GHz (optional)
29.50 to 30.10 GHz (optional)
50Ω
15 dB minimum
18 dB minimum
Type 'N' Female
Type 'N' Female (C-, X-, and Ku-Band)
15 dB nominal at minimum attenuation
0 to 10 dB
+10 dBm minimum
+20 dBm minimum
-60 dBc
-60 dBm
Input, either 5 MHz or 10 MHz ±5 dBm (optional)
