MBT-4000B Multi-band Transceiver System
Serial-based Remote Product Management
Command
Parameter (Instruction Code
Type and qualifier) BUC/BDC
Mute offline OFM=um MBT
Arguments for
Valid on
Command or
MBT or (Note that all arguments are ASCII numeric codes – i.e., ASCII codes
Response to
Query
2 bytes, numeric Command or Query.
Sets or returns muting for offline unit when in redundancy mode in the form
um, where:
u=1 (Unit 1) or 2 (Unit 2)
m=0 (Manual ) or (Automatic)
Note: The offline unit must start out as online for this command.
Where:
OFM=10 would be existing behavior for the block in Slot 1.
OFM=11 would force a mute of the block in slot one if Slot 1 is offline as
indicated by the switch position(blinking yellow or red LED). It would force
an "un- mute" of the block in Slot 1 if slot one is online and not faulted as
indicated by the switch position(steady green LED).
OFM=20 would be existing behavior for the block in Slot 2.
OFM=21 would force a mute of the block in Slot 1 if Slot 2 is offline as
indicated by the switch position(blinking yellow or red LED). It would force
an "un- mute" of the block in slot two if Slot 2 is online and not faulted as
indicated by the switch position(steady green LED).
These settings would be kept in NVRAM and would come from the factory
as "OFM=10" and "OFM=20"
Also, the offline unit must not be muted during this time.
The offline unit has to be set for online, otherwise the OFM command won't
work properly.
Description of Arguments
between 48 and 57)
6–15
MN/MBT4000B.IOM
Query
Response to Command (Instruction
(Target to Controller) Code and
qualifier)
OFM= OFM?u
OFM?
OFM!
Revision 1
Response to
Query
(Target to
Controller)
OFM=um
(same format as
command
arguments)
