MBT-4000B Multi-band Transceiver System
Serial-based Remote Product Management
Command
Parameter (Instruction Code
Type and qualifier) BUC/BDC
Set RTC Time TIM=hhmmss All
Retrieve Number N/A All
of unread
Stored Alarms
Terminal Status N/A All
Change
External XRF=x MBT
Reference Fault
Logic
Arguments for
Valid on
Command or
MBT or (Note that all arguments are ASCII numeric codes – i.e., ASCII codes
Response to
Query
6 bytes, numeric Command or Query.
Sets or returns the time, indicating the time from midnight, in the form
hhmmss where:
hh=hours, between 00 and 23
mm=minutes, between 00 and 59
ss=seconds, between 00 and 59
Example: TIM=231259 would be 23 hours, 12 minutes and 59 seconds
from midnight.
2 bytes, numeric Query only.
Returns the number of Stored Events that remain unread, in the form xx.
Example reply: TNA=18
1 byte, numeric Query only.
Returns the status of the Terminal Status in the form x, where:
x=0 (no change in status) or 1 (change in status)
Example: TSC=0
1 byte, numeric Command or Query.
Sets or returns enabling/disabling the software monitoring of the external
reference source in the form x, where:
x=0 (Ext Reference not monitored) or 1 (Ext Reference is monitored and
the lock state reported)
Note: If enabled and no source is present, a fault will be reported.
Example: XRF=1
Description of Arguments
between 48 and 57)
6–22
MN/MBT4000B.IOM
Query
Response to Command (Instruction
(Target to Controller) Code and
qualifier)
TIM= TIM?
TIM?
TIM *
N/A TNA?
N/A TSC?
XRF= XRF?
XRF?
Revision 1
Response to
Query
(Target to
Controller)
TIM=hhmmss
(same format as
command
arguments)
TNA=xx
(see Description of
Arguments for
details)
TSC=x
(see Description of
Arguments for
details)
XRF=x
(see Description of
Arguments for
details)
