Comtech EF Data MBT-4000B User's Installation And Operation Manual page 63

MBT-4000B Multi-band Transceiver System
Serial-based Remote Product Management
Command
Parameter (Instruction Code
Type and qualifier) BUC/BDC
Operating RF FRE=xxxxx.xxx BDC
Frequency BUC
Retreive N/A All
Firmware
Number
Monitor LNA N/A MBT
Current BDC
LNA Current LCS=sx MBT
Source BDC
LNA Current LCW=sxx MBT
Window BDC
Arguments for
Valid on
Command or
MBT or (Note that all arguments are ASCII numeric codes – i.e., ASCII codes
Response to
Query
9 bytes, Command or Query
numeric Sets or returns valid Operating RF frequency, in MHz.
For Ku BDCs:
FRE values: 10950-11700 MHz an LO of 10000 MHz is activated
FRE values: 11701-12250 MHz an LO of 10700 MHz is activated
FRE values: 12251-12750 MHz an LO of 11300 MHz is activated
Example: FRE=11300.000
Query only
Returns the Firmware Number of the unit.
Example: FRW=FW12357'cr''lf'
6 bytes, numeric Query only.
Returns the LNA/LNB Current Source Level in mA in the form s_xxx.x,
where:
s=1 (LNA A) or 2 (Bias Tee)
xxx.x= LNA Current Source Level in mA
Example:
<0001/LCM?2
>0001/LCM=2_045.3{cr}{lf}
2 bytes, numeric Command or Query.
Sets or returns LNA Current Source Enable in the form sx, where:
s=1 (LNA A AUX COMM) or 2 (LNB Bias Tee)
x=0 (Disable) or 1 (Enable)
Example: LCS=20 (turns off the LNB Bias Tee current)
3 bytes, Command or Query.
numeric
This command allows the user to set the alarm window in ± % of the
calibrated LNA/LNB Bias Current in the form sxx, where:
s=1 (LNA A AUX COMM) or 2 (LNB Bias Tee)
xx=Valid inputs are 20 to 50 in increments of 1%. Setting the value to 99
disables the alarm function.
Default is Disabled.
Example: LCW=230 sets alarm window for LNB Bias Tee to ± 30%.
Description of Arguments
between 48 and 57)
6–13
MN/MBT4000B.IOM
Query
Response to Command (Instruction
(Target to Controller) Code and
qualifier)
FRE= FRE?
FRE?
FRE*
FRE!
N/A FRW?
LCM= LCM?s
LCM?
LCM!
LCS= LCS?s
LCS?)
LCS*
LCS!
LCW= LCW?s
LCW?
LCW*
LCW!
Revision 1
Response to
Query
(Target to
Controller)
FRE=xxxxx.xxx
(see Description of
Arguments for
details)
FRW=FWxxxxx
LCM=s_xxx.x
LCS=sx
(same format as
command
arguments)
LCW=sxx
(same format as
command
arguments)
