Specifications

Technical:
Inputs (2): 1 HDMI Connector, Type A, 19 Pin Female
›
Outputs (4/8): 1 HDBaseT, Valens VS100 Class A, RJ45 Female
›
Output (1): RCA female for digital audio following SPDIF format (IEC 60958) . Supports sampling rate up to
›
192KHz; Balanced/unbalanced line level audio on 6-pin terminal block . Drives 2VRMS line audio input with a
sampling rate of 48KHz
Control Pass-Thru (Main Unit): 3-Pin Terminal Block for IR or RS-232 supporting voltage levels
›
from +0 .1V to +12V
Control (Rx Unit): IR In and Out on Phoenix Connector 5V IR sensor power . RS-232 on 3-Pin Phoenix
›
connector
Wired IR: modulated IR signal input, 0-5V TTL or -10 to +10V
›
Analog Audio Max Output Level: 4dBu on 150kΩ, DC coupling
›
Audio Bandwidth: 20Hz to 20kHz @ 0dBu
›
TND + Noise: 0 .33% @0dBu @ 1kHz » PCM Max Input Level: 1Vpp on 75Ω, AC coupling
›
PCM Max Output Level: 1Vpp on 75Ω, DC coupling
›
DDC Communication: EDID and HDCP Bi-directional buffering to Display and Source
›
Wired IR: modulated IR signal input, 0-5V TTL or -10to +10V
›
Power: +48V/1 .66A, 80W
›
General:
Regulation: CE, RoHS, WEEE, EAC
›
Rack Mount: 1U, 1 Rack Width (rack ears included)
›
Enclosure: Black Metal
›
Product Dimensions: 17 .3 x 5 .25 x 1 .72" (440 x 133 .5 x 43 .8 mm)
›
Shipping Carton Dimensions: 20 x 10 x 5 .7" (510 x 255 x 145 mm)
›
Product Weight: 6 lb
›
Shipping Weight: 9 lb
›
Accessories: IR Remote, UL Certified Power Supply
›
