EDID Control Settings

At times, your HDMI sources and display may not synchronize properly.
This is when EDID* control should be utilized. KD-1X2CS, KD-1X3CS,
KD-1X4CS Distribution Amps feature an internal library of default settings
that ensure that your HDMI source's output is compatible with the display
devices.
Please reset the unit by either unplugging and plugging the HDMI
connections, or via a power cycle for the new settings to take effect.
Rotary EDID Settings:
KD-1X2CS KD-1X3CS
EDID Settings EDID Settings
0 Copy EDID from 0 Copy EDID from
HDMI Output 1 HDMI Output 1
1 1080i, 2Ch Audio 1 1080i, 2Ch Audio
2 1080i, Dolby/DTS 5.1 2 1080i, Dolby/DTS 5.1
3 1080i, 2ch Audio 3 1080i, 2ch Audio
4 1080p, Dolby/DTS 5.1 4 1080p, Dolby/DTS 5.1
1080p, HD Audio 1080p, HD Audio
5 5
1080p, 2ch Audio 1080p, 2ch Audio
6 6
7 3D, 2ch Audio 7 3D, 2ch Audio
8 3D, Dolby/DTS 5.1 8 3D, Dolby/DTS 5.1
9 3D, HD Audio 9 3D, HD Audio
A 1280x1024 DVI A 1280x1024 DVI
B 1920x1080 DVI B 1920x1080 DVI
C 1920x1200 DVI C 1920x1200 DVI
D 1080p, 2Ch Audio D 1080p, 2Ch Audio
E 1080p, 2Ch Audio E Copy EDID from
HDMI Output 3
F Copy EDID from
HDMI Output 2 F Copy EDID from
HDMI Output 2
* EDID (Extended display identification data) is a data structure provided by a display
to describe its capabilities to a source device.
Rotary EDID Control Switch
KD-1X4CS
EDID Settings
0 Copy EDID from
HDMI Output 1
1 1080i, 2Ch Audio
2 1080i, Dolby/DTS 5.1
3 1080i, 2ch Audio
4 1080p, Dolby/DTS 5.1
1080p, HD Audio
5
1080p, 2ch Audio
6
7 3D, 2ch Audio
8 3D, Dolby/DTS 5.1
9 3D, HD Audio
A 1280x1024 DVI
B 1920x1080 DVI
C 1920x1200 DVI
D Copy EDID from
HDMI Output 4
E Copy EDID from
HDMI Output 3
F Copy EDID from
HDMI Output 2

Mechanical / Technical Specifications

Inputs 1 HDMI Connection
Outputs 2/3/4 HDMI Connectors
Bandwidth
TMDS bandwidth 10.2 Gb/s
Compliance with Fully licensed and compatible with all HDMI and HDCP techologies
HDMI Standard
Link Single Link: 1080p/60, 12 bit color depth, 1920x1200 max
Deep Color Support Supports digital video formats in Deep Color Mode at
up to 12 bits/color
Lossless Supports lossless compressed digital audio:
Compressed Digital Dolby ® TrueHD, Dolby
Audio
DDC Signal (Data) Input DDC Signal: 5 Volts p-p (TTL)
HDMI Video/Audio Input Video Signal: 1.2 Volts p-p
Signal
HDMI Connector HDMI Connector: Type A, 19 Pin Female
I2C Communication EDID and HDCP Bi-Directional Transparency from Display to Source
EDID Control Active outputs connected via HDMI, or from internal library of default
EDID settings
Power Source 5 Volt DC @ 1 Amp, 100-240 VAC, 50-60 Hz
Dimensions KD-1x2CS: W = 3.75", H = 1", D = 2.5"
KD-1x3CS: W = 5.5", H = 1", D = 2.75"
KD-1x4CS: W = 5.5", H = 1", D = 2.75"
Weight KD-1X2CS - 0.5 lb
KD-1X3CS - 0.9 lb
KD-1X4CS - 0.9 lb
