Mechanical / Technical Specifications

Inputs 1 HDMI Connector
Outputs 8/4/3/2 HDMI Connectors
Bandwidth TMDS bandwidth 10.2 Gb/s
Compliance With Supports HDMI1.3+, HDMI1.2, HDMI1. 1 , DVI1. 1 and HDCP
HDMI Standard
Link Single Link: 1080p/60, 12 bit color depth, 1920x1200 max
Deep Color Support Supports digital video formats in Deep Color Mode at up to 12 bits/
color
Supports lossless compressed digital audio
Lossless
Compressed Digital (Dolby ® TrueHD, Dolby
Audio
DDC Signal (Data) Input DDC Signal: 5 Volts p-p (TTL)
HDMI Video/Audio Input Video Signal: 1.2 Volts p-p
Signal
HDMI Connector HDMI Connector: Type A, 19 Pin Female
I2C Communication EDID and HDCP Bi-Directional Transparency from Display to Source
Active outputs connected via HDMI, or from internal library of default 4
EDID Control
EDID settings
Power Source 5 Volt DC @ 3 Amp, 100-240 VAC, 50-60 Hz
Dimensions KD-HDDA1X2, 1X3, 1X4 – W=8.5" , H=1.75" , D=4"
KD-HDDA1X8 – W=17" , H=1.75" , D=4"
KD-HDDA1X2, 1X3, 1X4 – 2 Lbs
Weight
KD-HDDA1X84 – 3.2 Lbs
® Digital Plus and DTS ™ -HD Master Audio)

Important Product Warnings:

1. Connect all cables before providing power to the unit.
2. Test for proper operation before securing unit behind walls or in hard to access spaces.
3. If installing the unit into wall or mounting bracket into sheet-rock, provide proper screw support
with bolts or sheet-rock anchors.

Safety Instructions.

Please be sure to follow these instructions for safe operation of your unit.
1. Read and follow all instructions.
2. Heed all warnings.
3. Do not use this device near water.
4. Clean only with dry cloth.
5. Install in accordance with the manufacturer's instructions.
6. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
7. Only use attachments/accessories specified by the manufacturer.
8. Refer all servicing to qualified service personnel. Servicing is required when the device has
been damaged in any way including:
Damage to the power supply or power plug
»
Exposure to rain or moisture
»
You MUST use the Power Supply provided with your unit or you VOID
the Key Digital ® Warranty and risk damage to your unit and associated equipment.
