Page 1: Operating Instructions
Phantom Series ™ HDMI Distribution Amplifiers with Audio De-Embedder, ® Coaxial Audio, Optical Digital Audio & Analog L/R Operating Instructions KD-HDDA1x2Pro KD-HDDA1x3Pro KD-HDDA1x4Pro The Experts in Digital Video Technology and Solutions ™... -
Page 2: Table Of Contents
Warranty Information ............8 Always follow the instructions provided in this Operating Manual. © 2013 Key Digital, Inc. All rights reserved. -
Page 3: Introduction
Introduction Key Digital Phantom Series HDMI/DVI Distribution Amplifiers are designed and engineered ® ™ to offer the best in quality, performance, and reliability while providing a cost effective HDMI/ DVI distribution solution. The KD-HDDA1x2Pro; KD-HDDA1x3Pro; KD-HDDA1x4Pro HDMI Distribution Amplifiers provide single input to multiple output distribution and maintain crystal-clear, pristine picture and sound quality. -
Page 4: Quick Setup Guide
› Step 6: Connect power to the KD-HDDA Pro unit › Step 7: Power on input/output devices › HDMI/DVI CAT6/STP Display 1 Up to 600’ KD-CATHD500FW with Key Digital ® KD-CAT6STP1X CAT6/STP HDMI/DVI KD-HDDA1x4Pro RS-232 KD-CATHD500FW Display 2 HDMI/DVI EDID Control... -
Page 5: Installation And Operation
KD-HDDA Pro Distribution Amplifiers can also be used with DVI-D sources and displays. For Audio Speakers these applications, use DVI to HDMI (Key Digital model number KD-MFHDMI or KD-FMHDMI) adapters. Note that while HDMI supports both video and audio over an HDMI cable, DVI-D supports only video. -
Page 6: Edid Control Settings
EDID Control Settings At times, your HDMI sources and display may not synchronize properly. This is when EDID* control should be utilized. KD-HDDA Pro Distribution Amps feature an internal library of EDID settings to ensure your HDMI source’s output is compatible with the display devices. Please reset the unit by either unplugging and plugging the HDMI connections, or via a power cycle for the new settings to take effect. -
Page 7: External Audio Outputs
External Audio Outputs Analog audio output via 3.5mm stereo phone jack 2 channel analog audio output from the selected HDMI › input source Converts only 2 ch. PCM audio from the HDMI input to › 2 channel analog audio output Only supports 2 ch. -
Page 8: Mechanical / Technical Specifications
Mechanical / Technical Specifications Inputs 1 HDMI Connector Outputs 4/3/2 HDMI Connectors Analog L/R Audio Output (3.5mm Stereo Phone Jack) Digital Audio Output (Coax; 1 RCA Jack + TOSLINK) Digital Audio Output (Optical: 1RCA Jack + TOSLINK) Bandwidth TMDS bandwidth 10.2 Gb/s Compliance With All HDMI versions and HDCP. -
Page 9: Important Product Warnings
Damage to the power supply or power plug » Exposure to rain or moisture » Power Supply Use: You MUST use the Power Supply provided with your unit or you VOID the Key Digital Warranty and risk damage to your unit and associated equipment. ®... -
Page 10: How To Contact Key Digital
For marketing and public relations information, please contact us at: Phone: 914-667-9700 › E-mail: marketing@keydigital.com › Repairs and Warranty Service Should your product require warranty service or repair, please obtain a Key Digital Return Material ® Authorization (RMA) number by contacting us at: Phone: 914-667-9700 ›... - Page 12 , led by digital video pioneer Mike Tsinberg, ® develops and manufactures high quality, cutting-edge technology solutions for virtually all applications where high quality video imaging is important. Key Digital ® is at the forefront of the video industry for Home Theater Retailers, Custom Installers, System Integrators, Broadcasters, Manufacturers, and Consumers.
