- Page 2 We believe Kirisun brand POC mobile radio, which always incorporates the latest technology, can bring great convenience to your life and work. We also believe that the quality and function of Kirisun two-way radio can meet your demands for reliable communication.
- Page 3 User Manual Notice to user ◆ Please read POC mobile radio’s manual carefully before using the product, so that user can operate the machine more freely. When user use this product, we think you have read this manual. ◆ Please keep the POC mobile radio’s manual for reference for future reference or users who use this product can read.
- Page 4 POC Trunked Mobile Radio ◆ Although all the texts are carefully checked, it is inevitable that there is a mistake and the company reserves all rights of final explanation. Safety instructions The government bans on operation the radio transmitter without permission in the jurisdiction scope.
- Page 5 User Manual Notice Please observe the following precautions to prevent fire, personal injury and radio damages ◆ Recommended radio usage is 1 minute for launching and 4 minutes for reception. Long-term launching or continuous using in high-power mode will cause the back of the machine to generate heat.
-
Page 6: Table Of Contents
POC Trunked Mobile Radio Contents Unpacking and Checking ..................7 1.1 Supplied Accessories ....................7 The Device ......................10 2.1 Appearance Description ..................10 2.2 Device Installation ....................12 2.3 Programmable Buttons ....................14 2.4 LED Indicator Status ....................15 2.5 LCD Icon Status .......................17 Basic Function and Operation ................19 3.1 Powering On/Off the Radio..................19 3.2 Standby........................19... - Page 7 User Manual 3.3 Adjust the volume ....................19 3.4 Selecting a Channel ....................19 3.5 Making a Call ......................20 3.6 Receive the call .......................20 3.7 Delay access to reply calls ..................20 3.8 Priority call .......................20 3.9 Call Types ........................20 3.10 Download history recording and playback ...............25 3.11 Location Information Report ..................25 3.12 Advanced Signaling Function ..................25 Technical Specifications ..................26...
-
Page 8: Unpacking And Checking
POC Trunked Mobile Radio 1 Unpacking and Checking Please carefully open the box, and check if the accessories listed below are contained in the package. For any missing or damaged item, please contact your local dealer for solution. 1.1 Supplied Accessories Material Quantity POC Mobile... - Page 9 User Manual Material Quantity Magnetic hand microphone hanger, with three M2.6*10 tapping screws Plastic handle screws, with matching flat washers, spring washers, plastic gaskets Fuse 3M glue stick Certificate of Approval User Manual...
- Page 10 POC Trunked Mobile Radio...
-
Page 11: The Device
User Manual The Device 2.1 Appearance Description... - Page 12 POC Trunked Mobile Radio Part Name Part Name Volume Control Knob Speaker PTT Key P1~P3(Programmable Keys) (Hand Microphone) Down Key Microphone Return Button Antenna Connector Emergency Button GPS Antenna Connector Hand Microphone port Cooling Fan LED Indicator Power Cable Connector LCD Display Screen SIM-2 Card Slot On/Off Button...
-
Page 13: Device Installation
User Manual The Menu Button TF Card Slot Left key Headphone port Up Key USB port Right key 2.2 Device Installation Note: * Please consider whether it is convenient to use when choosing the location of the installation in the car and avoid vehicles in poor conditions when driving on the personnel harm;... - Page 14 POC Trunked Mobile Radio 1）Please fix the mounting bracket in suitable place inside the vehicle with four M5*16 tapping screws. 2）Please use two plastic handle screws to secure the device to the mounting bracket 3）Connect the power cable First arrange 3 meters power line and connect the open end to the engine battery or other power supply (Attention: the power supply voltage can not exceed 26V).
-
Page 15: Programmable Buttons
User Manual Anticlockwise rotate the self-lock cover on the hand microphone until you can’t be rotated, then pull the plug out. Install Microphone Hanger Clip Using three M2.6*10 tapping screw to install the microphone Hanger clip at the place where it is convenient for your use (the microphone and the microphone line should install at the place doesn’t impact the safe drive), put the hand microphone hang on the microphone hanger. -
Page 16: Led Indicator Status
POC Trunked Mobile Radio Shortcut Keys Description No function. Press this button, mobile will be without any None response. Broadcast the user name Broadcast mobile radio correspondent user name by voice Broadcast mobile radio’s current group name by voice Broadcast group name Download history On the condition that the platform open recording function, it recording and playback... - Page 17 User Manual LED Indicator Status Mobile working status A、SIM card Not installed or SIM card installation error, voice prompt "failed to read the phone card" ; B、Not adding or configuring device on the business server ; Red light is always on C、Device added, channel select knob group mapping unsuccessfully ;...
-
Page 18: Lcd Icon Status
POC Trunked Mobile Radio Yellow light is flashing fast In the "registering" status; In” idle” or “off” status No instructions LCD Icon Status When operating the device, different icons appear on the display to indicate its current status Icon Description 2G / 3G signal receiving strength And Shows the strength of the receiving 2G / 3G signal. - Page 19 User Manual Icon Description GPS signal lock It shows that the mobile has got the GPS signal Group call It shows device is in group call status Individual call It shows device is in Individual call status All call It shows device is in all call status Dispatcher It shows mobile radios under dispatcher dispatching status Battery capacity...
-
Page 20: Basic Function And Operation
POC Trunked Mobile Radio Basic Function and Operation 3.1 Powering On/Off the Radio In the power off status, long press the radio On-Off button to power on the mobile. The power on screen will be shown, backlight will light and the power on alert will be heard. In the power on status, long press radio On-Off button until power off screen is shown to power 3.2 Standby... -
Page 21: Making A Call
User Manual 3.5 Making a Call When the current channel is a mapped channel (set in the management platform), directly press the PTT key to initiate a call to the current channel's default contact. 3.6 Receive the call When the current channel is a mapped channel (set in the management platform), a call to this unit on that channel (individual call , group call ) is received. - Page 22 POC Trunked Mobile Radio terminal may be in an invalid group (Not configured, the red light is on) or a valid group (green light is flashing slowly) 1）Select a Call Group In【Channel group】【UP key】 /【Down key】 to select. 2）Make a group call: Confirm the current status of the device is normal (green light is flashing slowly), press and hold 【PTT】...
- Page 23 User Manual Operate the pre-programmed [Individual Call] button (side button or top button, see " programmable button" part-2 ), enter Individual Call mode 3） Select an Individual Call receiver Press the left key to select an individual call receiver in "Contact". 4）...
- Page 24 POC Trunked Mobile Radio Note: Individual Call priority is higher than Group call, it can go across groups, regardless of the called user in any group System has a certain limited Individual Call talking time (40 seconds by default, it can be modified through the configuration tool), if the call is not ended within limited talking time, the system will automatically stop calling and prevent the call from a long time occupying.
- Page 25 User Manual display shows the current group name, group type, and name of all call’s Initiator, the green light remains on. After finished, it will have a short "beep" sound, and the light turns green and flash slowly. If the current enterprise users are offline, the green light flashes, the LCD screen shows "no answer", release the [PTT] key, end the call, enter the all call standby status.
-
Page 26: Download History Recording And Playback
POC Trunked Mobile Radio 3.10 Download history recording and playback After the management platform opens the recording and playback function, operating the pre-programmed [Historical Recording Download and Playback] button (P1, P2, P3) and can download and play back the latest five recordings. 3.11 Location Information Report Device’s GPS module can be positioned and reported to the management platform, management platform / dispatcher can display radio’s real-time position on the GIS map / historical trajectory. -
Page 27: Technical Specifications
User Manual Technical Specifications General WCDMA: 850MHz+900MHz +1900MHz+2100MHz Communication Mode & GSM: 850M+900M+1800M+1900MHz Frequency Bands WIFI &Bluetooth: 2.4GHz 2G: 200kHz; 3G: 5MHz Channel frequency (Follow 2G / 3G protocol, managed and Configured by the telecom interval carrier ) Operating Temperature -20℃... -
Page 28: Trouble Shooting
POC Trunked Mobile Radio Receiver Frequency Stability ±0.1 ppm 2G: BER < 0.001 when Î or = 1µV Sensitivity 3G: BER < 0.001 when Î or = 1µV Rated Audio Power Rated Audio Distortion 5% (typical) Trouble Shooting... - Page 29 User Manual Fault Reason Solution Mobile tail power plug Please make sure the power plug is tight. loose Battery voltage or supply Please make sure the supply voltage is Unable to boot voltage is less than 6V greater than 6V. Please replace the fuse, make sure the Fuse burned power is connected correctly after...
- Page 30 POC Trunked Mobile Radio Fault Reason Solution Please do simple cleaning outside. If still The speaker is clogged can’t solve the issue, contact the dealer or damaged or our authorized maintenance center. A, channel parameter setting is incorrect: re-set the parameters and try again; Platform parameter Cannot talk B, the default group identity of calling is...
- Page 31 User Manual FCC Notice: This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation.
- Page 32 POC Trunked Mobile Radio WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. RF Exposure The equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This device should be installed and operated with minimum distance 20cm between the radiator &...
- Page 33 保修卡 - 2 -...
