- Page 1 Professional wireless communication system solution supplier GP700 S ERV ICE M A NUA L Kirisun Communications Co.,Ltd. V211129...
-
Page 2: Table Of Contents
GP700 Service Manual Contents 1. OVERVIEW ....................................3 1.1 R ................................3 ANGE OF PPLICATION 1.2 S ................................. 3 AFETY RECAUTIONS 1.3 M ................................3 AINTENANCE ERVICE 2. APPEARANCE AND LE INDICATOR ............................ 4 2.1 A ....................................4 PPEARANCE 2.2 LED I .................................. -
Page 3: Overview
1.1 Range of Application This manual is applicable to the maintenance and repair of Kirisun GP700 PoC two-way radio and is intended only for the engineers and professional technicians who have been trained by Kirisun. The content of this manual may be updated because of technology development. -
Page 4: Appearance And Le Indicator
GP700 Service Manual Appearance and LE Indicator 2.1 Appearance Description Description Lower Side Key (Programmable) LCD screen Programmable by a dealer to achieve various functions. See 4.2 Programmable Keys. PTT Key Microphone Input voice. Press it to make a call and talk. -
Page 5: Led Indicator
GP700 Service Manual LED Indicator 2.2 LED Indicator LED Indication Device Status SIM card unavailable or installed improperly, or Voice announcement “No SIM card”, or Red light on Unlocking PIN code unlocking failed Green light on In an individual/group/all call... -
Page 6: Rf Circuit Diagram
GP700 Service Manual The radio is composed of these function modules: LCD module, key detector module, audio power amplifier, SIM card module, Wi-Fi module, GPS module and BT module. 3.2 RF Circuit Diagram The RF circuit in the radio is integrated into the SC20 module. Signals are received and transmitted to RF module through the main antenna. -
Page 7: Power Circuit
GP700 Service Manual The Wi-Fi / GPS functions are achieved by the SC20 module, and signals are received and transmitted to this module through the Wi-Fi and GNSS antennas. 3.4 Power Circuit The SC220 module is powered directly by the battery, and the power is converted and distributed by the module. - Page 8 GP700 Service Manual The SC20 module processes digital voice signals for the DSP, the input voice signal “HPH_R” goes into the audio frequency amplifier NS4150, achieving the amplification and power drive of analogue voice signals.
-
Page 9: Sim Card Interface Circuit
GP700 Service Manual 3.6 SIM Card Interface Circuit SIM card data is read by the H200 module. The circuit is composed of the card clock signal SCLK, the card reset signal SRST, the card data signal SIO and the power supply detection signal PMU, for which static is avoided using a TVS (transient voltage suppressor) or ESD (electrostatic discharge) component. -
Page 10: Key Circuit (On Lcd Board)
GP700 Service Manual 3.8 Key Circuit (on LCD Board) Matrix keys are used. The chip AW9523B judges whether a key is pressed by scanning the level at the GPIO port. The level is processed by the AW9523B, converted into data, and sent to the SC20 module for command execution. -
Page 11: Lcd Circuit (On Lcd_Keyboard Board)
GP700 Service Manual 3.9 LCD Circuit (on LCD_Keyboard Board) The LCM circuit is mainly composed of a LCD screen and a LED backlight driver, the on-off control of which is achieved by a field effect transceiver. The interface level of the LCD and the SC20 module are different and converted by the UM3204Q. The circuit provides an output port for the data after processing by the H603 module. -
Page 12: Functions And Parameters
GP700 Service Manual Functions and Parameters 4.1 Functions Availability Category Function Note (Y/N) Power on/off Individual call Group call Voice All call Broadcast call Message Data Basic Keypad lock LCD backlight Remaining battery capacity indication Man down Stun Kill Revive... -
Page 13: Icons
GP700 Service Manual Function Description User announcement Announce the user name of the radio. Group announcement Announce the current group in which the radio is in. Playback Play back the latest 30 voice records. Bluetooth on/off Enable/disable Bluetooth function. Wi-Fi on/off Enable/disable Wi-Fi function. -
Page 14: Advanced Functions
Kirisun CPSc Setup V1.X.X. Take the following steps to set parameters of the radio on a PC. 1. Install the Kirisun CPSc Setup V1.X.X on the PC. (Select a language during installation.) 2. Power on the radio. 3. Connect the radio to the PC using the programming cable. -
Page 15: Installing And Uninstalling The Antenna
GP700 Service Manual Uninstalling the Battery 1. Power off the radio. 2. Slide the latch in the indicated direction, and the battery will go up. (Figures ① and ②) 3. Slice the battery in the indicated direction to take it down. (Figure ③) If the belt clip is installed, please first press the upper part of it so that it goes up. -
Page 16: Detaching Housing From The Base
GP700 Service Manual 5.5 Detaching Housing from the Base 1. Remove the antenna; 2. Remove the Power/Volume knob; 3. Remove the knob nut and the antenna nut; 4. Unscrew the two screws of the belt clip and the belt clip;... -
Page 17: Explosion Diagram
GP700 Service Manual 5.7 Explosion Diagram 36 35 33 32 19 20 Table 1 Material List (Structural Section) Material Code Name Specification 7MHP-4187-01B-W0 Key cover PC1414, black, etched Sound-permeable membrane of 7MHP-4309-05A-J0 PC,black speaker 7MHB-4309-01A-W0 Speaker dust screen Non-woven fabrics, black... - Page 18 GP700 Service Manual 147K03000002 Aluminum housing ADC12, natural color, electroplanting Silicone rubber, outer diameter 4mm, wire 7MHR-4072-06A-W0 O-shaped ring diameter 1.0mm 7SMS-025075M-SZYB Torx mushroom-head machine Stainless steel screw 157F15000028 SIM card holder PVC sheet, black, no surface treatment 7GCM-020015010 Foam EVA, black, adhesive, 1.0mm thick...
-
Page 19: Tuning
GP700 Service Manual 8ATX-4309-WA1 Public-network antenna 7MHJ-4187-02A-W Dual-side adhesive for side key 3M9448 157F15000060 Foam for FPC stiffener PORON,black,adhesive,6.0*4.0*1.0 Side-key FPC board SMD 6SS1-4187-HK2A nesting φ6SUS301 circular, 250 gf 7MHS-4187-02C-W Side-key metal dome 7MHR-4309-03A-W0 PTT key Silicon rubber, black, 60 degree... - Page 20 GP700 Service Manual R234,R235,R302,R306,R316,R52 2RS1-10-104J Chip resistor 0,R521,R522,R523,R254,R117 2RE1-20-0R056 SMD precision resistor R567 C204,C206,C211,C405,C406,C40 2CC1-10-NP0500-330 Multi-layer chip capacitor 2CC1-10-X7R500-102K Multi-layer chip capacitor C806,C808 2CC1-10-X7R100-473K Multi-layer chip capacitor C426 2CC1-10-X5R100-104K Multi-layer chip capacitor C423,C424,C428 2CC1-10-X7R100-224K Multi-layer chip capacitor C501,C100,C102,C425 2CC1-16-X5R6R3-475K Multi-layer chip capacitor...
- Page 21 GP700 Service Manual Figure 1 Schematic Diagrams of LCD_Keyboard Board 旋钮 KEYPAD SIDEOKEY PMOS_WPM2341 D T A 1 2 3 J E TP17 TP16 USB_BOOT TP20 KEY_BL FORCE_USB_BOOT [1] Q903 COLUMN0 [1] ROW0 SUB_SW1 COLUMN1 [1] ROW1 DIODE-RB521S-30 POWER_ON COLUMN2...
- Page 22 GP700 Service Manual Figure 2 Top-Layer and Bottom-Layer Layout Drawings of LCD_Keyboard Board 口 KEY100 三 E二二二3 E二二二3 曰 些 EB 间内叫 0301 ＠ 因匾 ！ 用 氧 ～ 月 轧2 π 片 ［ 干 刁 曰 ： 一一 日...
- Page 23 GP700 Service Manual ＝ θ CON1 136P04000073 E二二2 GP700-LCD V2.0 ： � 且 因 曰 ： 剧 。 世 同 阳 时U 阳 － 门〕〕 曰 川 －－ 阳 LJRY102 写 ， · J二 「 口 出 MIC401 巳＝ ：...
