  • Page 1 MARK I I you can WANHAO Duplicator 6 Plus USER MANUAL...

  • Page 3: Table Of Contents

    From SD-card to print your file Maintenance for your WANHAO D6 Plus In General Change filament and material feeder Lubricating the axes G. Troubleshooting and support for the WANHAO D6 Plus Simple Troubleshooting tips Contact support Terminology Safety and Compliance...

  • Page 4: Welcome To Wanhao D6 Plus

    WELCOME TO THE WANHAO D6 PLUS D6 PLUS...

  • Page 5: A1. The Wanhao Experience

    You might be familiar with earlier types of WANHAO or other 3D-printers. It is essential that your read this manual carefully as there are a lot of new procedures with WANHAO D6 Plus. The wanhao experience Welcome to the D6 Plus...

  • Page 6: A2. Specifications Of The Wanhao D6 Plus

    Technical Specifications Primary Attributes FDM Type Printer, Fully assembled. Entry Level of the Technology Desktop Home Printer. Software CURA, Repetier Host, Simplify 3D, & Others Extruder System MK11 Extruder with Full Metal Hot End Material Support PLA, PVA, PC, PETG, ABS, Most Other Filaments Bed Leveling Auto bed leveling,Manual leveling Max Printable Area...

  • Page 7: Get Started And Unpack Your Wanhao D6 Plus

    GET STARTED & UNPACK YOUR WANHAO D6 PLUS D6 PLUS...

  • Page 8: B1. Unboxing Your Wanhao D6 Plus

    B1. Unboxing your D6 Plus 1. Place the D6 Plus box on a stable surface, Placing it centrally on the fl oor will provide the best accessible position for unpacking. 2. Open the box. Here you will see the User Manual. We recommend that you use the User manual to guide you through the setup process fi rst...
  • Page 9 7. Cut the 2 black bindings from the side of the printer. 8.Pull the filament box out from the Printer gently. 9. Pull the Wanhao Masking mat out from the printer gently. 10. Pull the Spare parts box out from the printer gently.
  • Page 10 11. Wrap the protection foam and pull it out from the printer 12.. Cut the X axis rail secure binding right at front top of printer. 13. Cut the Y axis rail secure binding 14. Get printer out from the bottom foam cave.
  • Page 11 16.Loose the locking bolt by 1.5mm hex wrench anti-clockwise. 17.Turn the control button pillar flat side upward. 18. Insert the button onto the pillar. Make sure the bolt hole is right towards the flat pillar side. 19.To lock the button by turning the bolt clockwise with 1.5mm hex wrench B1.

  • Page 12: B2.What's In The Box

    B2.What’s in the box Besides your D6 supplied with SD card in the 3D printer, there are a lot of essential accesoires that comes with this 3D printer. All the following parts should be in the box, please check contents. Spool holder Tweezers Filament spool...
  • Page 13 B3. D6 Plus at a glance 1. MK11 extruder Leveling Sensor 3. WANHAO printing mat 4. Super thick Guiding Rod 5. SD card slot 6. LCD Display 7. Navigation Dial 8. Cable Quick Coupler 9. Cable locker 10. Extruder Cable 11.

  • Page 14: B3. Wanhao D6 Plus At A Glance

    INSTALLING PARTS ON YOUR WANHAO D6 PLUS D6 PLUS...

  • Page 15: C1. Installing Power Supply

    C1. Installing power supply Attaching power supply Now the next step is to give the D6 plus power. This is done by attaching the internal power supply. 1. First make sure the power switch is in the OFF position, this is when the button at the back is pressed to [0].

  • Page 16: C2. Installing Filament: Spool Holder And Guide

    C2.Installing filament: spool holder Attaching the spool holder 1. Turn the Z axis screw clockwise to raise the platform. 2. Install the spool holder. Insert the M30 nut from the printing chamber into the Hex cave. Note: the wrench mark on the nut toward 2 clock direction.

  • Page 17: C3. Switch On/Off The Wanhao D6 Plus

    C3.Switch on/off the D6 Plus Switch off the D6 plus The on/off button (a.k.a. ‘ – | O ’) of the D6 Plus is located at the back. The ‘ O ’ represents off and the ‘ – ’ represents on. When it’s switched to the ‘...

  • Page 18: First Use Of Your Wanhao D6 Plus

    FIRST USE OF YOUR WANHAO D6 PLUS D6 PLUS...

  • Page 19: D1. First Time Startup

    D1. First time startup This chapter guides you through the steps and the first run of the D6 plus. After you switch on your D6 plus, the display will light up and guide you through . Use of the display You can navigate through the display by using the button.

  • Page 20: D2.Leveling The Build Plate

    D2.Leveling the build plate By click the [AUTO BED LEVELING], the printer would start sensing 9 different spot on the building plate and record the offset data. All the leveling procedure would be fi nished automatically. NOTE: After transportation you might want to level your build plate to ensure your 3D models stick well to the build plate NOTE: Before proceed anything ,use a soft fabric to Wipe off the dusts from the building plate surface and clean it.
  • Page 21 D2. Manual leveling the build plate If the Auto leveling cannot meet your requirement or you would like to have specific Leveling. You can Manual level the bed. Click ADVANCED – MANUAL LEVEL THE BED NOTE: Manual leveling would remove all the former leveling parameters. By confirm yes, you can go on manual leveling.

  • Page 22: D3. Loading Filament Material

    D3. Loading fi lament material Now that you have completed the initial leveling tasks. Please navigate----ADVANCE---Move STEP where we are going to insert fi lament material in the material feeder. Please make sure you have a fi lament spool positioned over the spool holder, guided along the filament guide, with the filament in counter clockwise direction.
  • Page 23 D3. Loading filament material (continued) You can [CONTINUE] this step, when the material is loaded until it reaches the Mk11 extruder nozzle. The filament is being pulled through the MK11 extruder quickly. Once you see the filament getting out of nozzle, push the button to stop extruding. Follow the instruction on the display.

  • Page 24: D4. Make Your First 3D Print

    [ARE YOU READY] to go to the next step! [LET’S PRINT] to start 3D printing! Your SD-card comes with the fi le [wanhao Robot] click the button if you would like to print this fi le. D5. Resume Printing after...

  • Page 25: D5. 3D Printing And Print Removal

    D6. 3D printing and print removal After you have chosen your [wanhao Robot] to print your D6 will prepare itself and heat its print head nozzle and build plate. (This can take up to 5 minutes) WARNING: Do not touch the extruder while it is heating and in use.

  • Page 26: Make A Print File With Cura Software

    MAKE A PRINTFILE WITH CURA SOFTWARE...

  • Page 27: E1. Downloading And Installing Cura

    E1. Downloading and installing Cura The preferred software for your D6 is Cura from wanhao. This software package prepares your 3D model into instructions that your D6 uses to produce an object. 1. The Cura software package can be downloaded from the “Down load ”...

  • Page 28: E2. Cura Software Interface

    E2. Cura software interface This is the main screen of Cura. Here you can choose which object or objects to print. And how you want them to be printed. 1. Load file 5. Print type profiles 9. Scale model options Click this button to load an 3 options to choose a print Option to change the scale of...
  • Page 29 E2. Cura software interface (continued) The following mouse actions are used to work, navigate and view the 3D model: Leftmouse button Scrollwheel button Select objects. Hold and move Use the scroll wheel to zoom the mouse to drag in or out. object on the 3D print area.

  • Page 30: E3. From Youmagine.com To Load File In Cura

    E3. From YouMagine.com to load file in Cura Now that you are familiar with Cura we continue to explain how you can download a 3D file from YouMagine.com and load this into Cura. Youmagine. com is an online community for 3D printing. 1.

  • Page 31: E4. Preparing A 3D Model

    E4. Preparing a 3D model 1. Most 3D printable files that you will find on YouMagine.com are in the STL format. Let’s start by clicking on the Load button in Cura. 2. When you have loaded a file into Cura you might notice the progress bar.

  • Page 32: E5. From Sd-Card To Print Your File

    E5. From SD-card to print your file 1. After saving the file and safely ejecting your SD-card from your computer, it is time to insert it in the SD-card Slot at the front of your D6 Plus 2. By rotating the button and selecting [PRINT], you can now choose your desired print model from the SD-card.

  • Page 33: Maintenance For Your Wanhao D6 Plus

    MAINTENANCE FOR YOUR WANHAO D6 PLUS...

  • Page 34: F1. In General

    F1. In General To achieve the best possible results from your D6 Plus, some basic annual maintenance is recommended. This chapter contains tips which helps you to keep the D6 Plus running at it’s best. Before you make a print a quick check is advised. A visual check is recommended to see if there is not any: - old prints/objects on the build plate.

  • Page 35: F2. Change Filament And Material Feeder

    F2. Change filament and material feeder Removing filament In the D6 Plus the filament material can be changed. As you have learned in previous steps there is no need to do this all by yourself because the D6 Plus helps you with that. 1.

  • Page 36: F3. Lubricating The Axes

    F3. Lubricating the axes Z-Axis After approximately every half year the threaded rod on the z-stage has to be lubricated. A green grease (Magnalube-G) is included with the D6. This grease is the lubrication which has to be used on the threaded Z-stage rod.

  • Page 37: Troubleshooting And Support For The Wanhao D6 Plus

    TROUBLEHOOTING AND SUPPORT FOR THE WANHAO D6 PLUS...

  • Page 38: G1. Simple Troubleshooting Tips

    G1. Simple Troubleshooting tips In case something goes wrong with your D6, the following chapter will help you. From diagnosing and fixing the problem yourself to contacting support. Print detaches during printing or print does not stick at all. Cause Build plate is not properly leveled.
  • Page 39 G1. Simple Troubleshooting tips (continued) Not enough material is released from the nozzle. Cause Material feeder on the back of the D6 Plus is ticking while printing. Nozzle is blocked or partially blocked by dirt or burned material. Solution Increasing the print temperature to 260C while printing in an attempt to clear the blockage.

  • Page 40: G2. Contact Support

    See support@wanhao3dprinter.com for details. There is also a wealth of information, tips and amazing wanhao printed objects on our busy online forum community. These forums can be reached online at https://groups.google.com/forum/#!forum/wanhao-printer-3d...

  • Page 41: G3. Terminology

    SD-card: Secure Digital memory card that can store board. Gantry: The construction of metal rods that allow digital data. The card that can be used with the wanhao movements on the x- y- and z-axis. has to be an SD-card and not an SDHC card.

  • Page 42: G4. Safety And Compliance

    G4. Safety and Compliance Warning This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. G2. Contact support Troubleshooting and support for the D6 Plus...

  • Page 43: Repair And Refurbished Goods Or Parts Notice

    Please be assured though, refurbished parts or replacements are only used where they meet WANHAO’s stringent quality specifi cations. If at any time you feel your repair is being handled unsatisfactorily, you may escalate your complaint.

  • Page 44: Notes

    NOTES: Notes...
  • Page 46 WANHAO Precision Casting Co.,Ltd 77, RENMING ROAD, JINHUA, CHINA WANHAO Help Desk 86-571-23290996 support@wanhao3dprinter.com (Operating Hours: Mon - Sat; 8:00am - 5:00pm) www.wanhao3dprinter.com...
