Summary of Contents for Enwork Ambition
- Page 1 Ambition Acoustic Screen Acoustic Screen Installation Installation Instructions AM0001 – REV B 10/1/18...
- Page 2 INSTALLATION GUIDE 1) Parts and Fasteners Included Drill/Driver #1 Phillips Bit #3 Square Bit BTDIV BRKT Screw 1 #12 x 0.50 Phillips Screw...
- Page 3 INSTALLATION GUIDE 2) Assembly Overview 1.) Slowly attach BTDIV BRKT brackets to screen using #12 x 0.50 screws. Do not over tighten. ***WARNING: TORQUING SCREWS WILL RESULT IN CREATING VISUAL INDENT ON BACK SIDE*** Fig. 1 Fig. 2 2.) Using Screw1, attach screen to underside of worksurface as shown in Fig 2. *Note: Screen needs to be held tight against edge of surface while installing*...
- Page 4 12900 Christopher Drive Lowell, MI 49331 800.815.7251 www.enwork.com Specifications subject to change without notice.
